STS STD Ship Pneumatic Rubber Fender Marine Ball Customized Color

Key Attributes
Brand Name: Henger
Model Number: CAL
Place of Origin: China
Certification: CCS/BV/GL/ABS/LGDNV
Minimum Order Quantity: 1 set
Price: USD 400-2000/set
Supply Ability: 100sets/Month
Payment Terms: L/C, T/T, Western Union, MoneyGram
Standard Packaging: Naked/Pallet/wooden box

Product Summary

Pneumatic Rubber Fender Marine Ball Can Be Customized Color STS,STD,Ship Qingdao Henier Ship Supplies Co., Ltd. Qingdao Henier Ship Supplies Co., Ltd. is located in the beautiful coastal city of Qingdao. Is a professional manufacturer of marine products, such as inflatable rubber fenders, foam ...

Product Custom Attributes

Highlight

Ship Pneumatic Rubber Fender

,

STD Marine Pneumatic Rubber Fender

,

12m Rubber Fender Marine Ball

Pin Material:
Q235hot Galvanizing/316Stainless Steel
Kind:
Pin Material
KPA:
50Kpa/80Kpa
Payment Method:
LC/TT,Western Union, MoneyGram
Production Phase:
100sets/Month
Specifications:
Up To 4.5*12m,Customized
Application:
STS,STD,Ship,Collision Avoidance
Texture:
Rubber
Color:
Gray/Black/Customized
Product Description

Pneumatic Rubber Fender Marine Ball Can Be Customized Color STS,STD,Ship

                                                              Qingdao Henier Ship Supplies Co., Ltd.

    Qingdao Henier Ship Supplies Co., Ltd. is located in the beautiful coastal city of Qingdao. Is a professional manufacturer of marine products, such as inflatable rubber fenders, foam fenders, marine rubber airbags, marine navigation marks, and mooring buoys. The production department is located in Jinkou Town, Jimo City, about two hours' drive from Qingdao Port. The geographical position is superior and it has 20 years of production experience in the production of marine supplies. The sales department is located in the Shibei Central Business District with convenient transportation, bringing together professional sales talents from all over the country. Hener's sales team has won the trust of customers from all over the world with a good reputation and professional services. Our service concept is to leave the simplicity to the customers and the complexity to ourselves, and use the most professional service attitude to bring customers the best shopping experience.

                        STS STD Ship Pneumatic Rubber Fender Marine Ball Customized Color 0



                                  Product Description

Pneumatic rubber fender is one kind of ship berthing, cushioning and protection equipment, which uses compressed air as the buffer medium to prevent collision when the ship is berthing. These pneumatic rubber fenders play a vital role in the safe operation of ship berthing and mooring, and are widely used in the fields of ship, marine facility, marine platform, port and dock, yacht and so on.The pneumatic rubber fender is more economical and durable than the ordinary rubber fender, so it is more popular and widely used.

                              STS STD Ship Pneumatic Rubber Fender Marine Ball Customized Color 1

                              STS STD Ship Pneumatic Rubber Fender Marine Ball Customized Color 2


                                     STS STD Ship Pneumatic Rubber Fender Marine Ball Customized Color 3

                          Pneumatic Rubber Fender Usage

a.Dock protection


Many ships are berthed at the wharf every day. If not protected, it will soon be damaged and affect the normal operation of the wharf

b.Ship protection

Various collision problems encountered during berthing can fully protect the hull

c.Ship to ship protection

Ships in the ship operation, there is a good buffer, protect the role of the hull
                                     STS STD Ship Pneumatic Rubber Fender Marine Ball Customized Color 4                                                                    STS STD Ship Pneumatic Rubber Fender Marine Ball Customized Color 5


Manufacturer advantage



With its own production workshop, the communication is more convenient,

the price is more advantageous, and the delivery date can be adjusted flexibly.





Geographical advantage



It is close to Qingdao Port and has an advantage in cargo transportation.



Products are sold all over the world



The main sales market is located in Southeast Asia, and gradually develops to other regions such as Europe and America with the help of good reputation.
                       STS STD Ship Pneumatic Rubber Fender Marine Ball Customized Color 6

                                          Unique Design of Henger Pneumatic Rubber Fender


1 Pneumatic 50 Kpa fender size and performance requirements

Nominal size
diameter x
lenghth (mm)
Initial internal
pressure kpa
Guaranteed energy
absorption(GEA)
Reaction force at
GEA deflection
(R)
Hull
presure(Internal
pressure)at GEA
deflection(p)
Minimum value at
deflection 60+5%
KJ
Tolerance +10%
KN
Reference value
Kpa
500*1000 50Kpa 6 64 132
600*1000 50Kpa 8 74 126
700*1000 50Kpa 17 137 130
700*1500 50Kpa 17 137 135
1000*1500 50Kpa 32 182 122
1000*2000 50Kpa 45 257 132
1200*2000 50Kpa 63 297 126
1350*2500 50Kpa 102 427 130
1500*2000 50Kpa 400 108 131
1500*2500 50Kpa 134 499 131
1500*3000 50Kpa 153 579 132
1700*3000 50Kpa 191 639 128
2000*3500 50Kpa 308 875 128
2000*4000 50Kpa 352 1000 132
2500*4000 50Kpa 663 1381 137
2500*5500 50Kpa 943 2019 148



2 Pneumatic 80 Kpa fender size and performance requirements



Nominal size
diameter x
lenghth (mm)
Initial internal
pressure kpa
Guaranteed energy
absorption(GEA)
Reaction force at
GEA deflection
(R)
Hull
presure(Internal
pressure)at GEA
deflection(p)
Minimum value at
deflection 60+ 5%
KJ
Tolerance +10%
KN
Reference value
Kpa
500*1000 80Kpa 8 85 174
600*1000 80Kpa 11 98 166
700*1500 80Kpa 24 180 177
1000*1500 80Kpa 45 239 160
1000*2000 80Kpa 63 338 174
1200*2000 80Kpa 88 390 166
1350*2500 80Kpa 142 561 170
1500*3000 80Kpa 214 761 174
1700*3000 80Kpa 267 840 168
2000*3500 80Kpa 430 1150 168
2500*4000 80Kpa 925 1815 180
2500*5500 80Kpa 1317 2653 195
3300*4500 80Kpa 1640 2476 171
3300*6500 80Kpa 2532 3961 191
3300*10600 80Kpa 4281 6907 208
4500*9000 80Kpa 6633 7551 192
4500*12000 80Kpa 9037 10490 202



After you receive the fender, if there is a problem with the fender




1.If there is a problem with our fenderion, we can replace you with a new fender for free.


2.If it is the minor wear and tear of the fender during your daily normal use, and there is no need to ship it back to China, we can provide you with a solution for remote assistance.


3.If the fender problem is caused by improper operation in your daily use, we cannot provide free fender replacement, you can pay the cost to ship it back to China for repair, or we can remotely assist you to find a solution.
