Docking Boat Yokohama Pneumatic Fender Inflatable Rubber Fender

Docking Boat Yokohama Pneumatic Fender Inflatable Rubber Fender
Docking Boat Yokohama Pneumatic Fender Inflatable Rubber Fender
video play

Large Image :  Docking Boat Yokohama Pneumatic Fender Inflatable Rubber Fender

Product Details:
Place of Origin: China
Brand Name: Henger
Certification: CCS BV ISO17357
Model Number: 500mm x 1000mm-3300mm x 6500mm
Payment & Shipping Terms:
Minimum Order Quantity: 1 PC
Price: USD 230 TO USD 7000 PER PC
Packaging Details: International General Packaging
Delivery Time: 5-8 DAYS
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 300 PC PER WEEK
Detailed Product Description
Product Name: Pneumatic Rubber Fender/Marine Fender/Yokohama Fender Brand: Henger
Material: Natural Rubber Specification: Dia 0.5m-4.5m, L 0.7m-9m/Customized
Certificate: CCS / BV / LR / ISO17357/DNV/SGS Shelf Life: 24 Months
Working Pressure: 50kpa/80kpa Application: Dock,Ship,Ship To Ship
Service Life: 10 Years Production Time: 5-10 Days
Payment Method: L/C, D/A, D/P, T/T, Western Union, Moneygram Accessories: Tyre Sheath/Swivel/Shackle/Chain
Packing: Naked/Pallet Colour: Black/Blue/As Requirements
High Light:

0.5m Yokohama Pneumatic Fender

,

Docking Yokohama Pneumatic Fender

,

Docking Inflatable Rubber Fender

Rubber Pneumatic Docking Boat Yokohama Type Marine Fender



Product Introduction of Rubber Inflatable Fender

Rubber Inflatable Fender also called pneumatic fender, rubber fender, yokohama fender,made by rubber & multi layer of rubber-dipped tyre fabric, is a leading anti-collision device for marine application in the world today.

Rubber Inflatable Fenders have become an ideal ship protection medium against collision among ship-to-ship (STS), ship to quay (STQ) and ship-to-berthing (STB), they are widely used for large tankers, vessels, docks, harbor wharfs and ocean platforms.

Constructions

Out rubber: rubber layer that covers the outside of the fender to protect the cord layers and the inner liner rubber from abrasion and other external forces.
Inner rubber: liner of a rubber membrane that seals the pressurized air inside the fender.
Synthetic-tyre-cord layer for reinforcement: layer made of synthetic tyre-cord fabric,which maintains the internal air pressure of the fender.

Application of Rubber Inflatable Fender

--Oil and gas tankers
--Fast ferries and aluminium vessels
--Temporary and permanent installations
--Rapid response and emergencies
--Can support large panels
--Very low reaction and hull pressure
--Suitable for small and large tidal ranges
--Maintains large clearances between hull and structure


The following are the product specifications and detailed parameters:





Pneumatic 50 fender size and performance requirements

Nominal size diameter x length

mm

Initial internal pressure

kPa

Guaranteed energy absorption (GEA) Reaction force at GEA deflection(R) Hull pressure (Internal pressure) at GEA deflection (P)
Minimum value at deflection 60±5% kJ Tolerance±10 % kN

Reference value

kPa

500 x 1000 50 6 64 132
600 x 1000 50 8 74 126
700 x 1500 50 17 137 135
1000 x 1500 50 32 182 122
1000 x 2000 50 45 257 132
1200 x2000 50 63 297 126
1350 x 2500 50 102 427 130
1500 x 3000 50 153 579 132
1700 x 3000 50 191 639 128
2000 x 3500 50 308 875 128
2500 x 4000 50 663 1381 137
2500 x5500 50 943 2019 148
3300 x 4500 50 1175 1884 130
3300 x 6500 50 1814 3015 146
3300 x 10600 50 3067 5257 158
4500 x 9000 50 4752 5747 146
4500 x 12000 50 6473 7984 154





Pneumatic 80 fender size and performance requirements

Nominal size diameter x length

mm

Initial internal pressure

kPa

Guaranteed energy absorption (GEA) Reaction force at GEA deflection (R) Hull pressure (Internal pressure) at GEA deflection (P)
Minimum value at deflection 60±5% kJ Tolerance±10% kN

Reference value

kPa

500 x 1000 80 8 85 174
600 x 1000 80 11 98 166
700 x 1500 80 24 180 177
1000 x 1500 80 45 239 160
1000 x2000 80 63 338 174
1200 x 2000 80 88 390 166
1350 x 2500 80 142 561 170
1500 x 3000 80 214 761 174
1700 x 3000 80 267 840 168
2000 x 3500 80 430 1150 168
2500 x 4000 80 925 1815 180
2500 x 5500 80 1317 2653 195
3300 x 4500 80 1640 2476 171
3300 x 6500 80 2532 3961 191
3300 x 10600 80 4281 6907 208
4500 x 9000 80 6633 7551 192
4500 x 12000 80 9037 10490 202



Advantages of Qingdao Hunger marine inflatable fenders:

1. The rubber marine fenders warranty period can be up to 24 months

2. The rubber used for the fender has passed SGS certification and is the best rubber on the market. It is wear-resistant and not easily broken.

3. Yokohama Dock Rubber Fender can pass the certification of major classification societies and fully comply with the ISO17357-2014 standard.

4. We have a professional service team, which can save you communication time





QINGDAO HENGER SHIPPING SUPPLIES CO.,LTD



Rubber Marine Fenders is widely used in ship-to-ship (STS) transshipment operations, terminals and various ships worldwide.



Since its establishment, Henger has provided more than 20,000 fenders for ship-to-ship and ship-to-dock operations serving our important customers worldwide. These fenders are used in the safe operation of ship mooring and mooring. Plays a vital role.



Technical advantages
Qingdao Henger inflatable fender has introduced the latest Yokohama Floating Fender production technology from Yokohama, Japan, and hired experienced engineers at home and abroad for training and guidance throughout the year. "Floating inflatable rubber fender" is produced according to international quality standards.


Production advantages
Qingdao Henger has accumulated 20 years of professional rubber product production experience. It is an excellent company in the region, with strong technology and capital, and is a supplier of stable quality marine fenders and government marine supplies.
