ISO 17357 Floating Pneumatic Rubber Fender Yokohama Type Marine Fender

ISO 17357 Floating Pneumatic Rubber Fender Yokohama Type Marine Fender
ISO 17357 Floating Pneumatic Rubber Fender Yokohama Type Marine Fender ISO 17357 Floating Pneumatic Rubber Fender Yokohama Type Marine Fender ISO 17357 Floating Pneumatic Rubber Fender Yokohama Type Marine Fender ISO 17357 Floating Pneumatic Rubber Fender Yokohama Type Marine Fender ISO 17357 Floating Pneumatic Rubber Fender Yokohama Type Marine Fender ISO 17357 Floating Pneumatic Rubber Fender Yokohama Type Marine Fender

Large Image :  ISO 17357 Floating Pneumatic Rubber Fender Yokohama Type Marine Fender

Product Details:
Place of Origin: China
Brand Name: Henger
Certification: CCS / BV / LR / ISO17357/DNV/SGS
Model Number: 500mm*9000mm
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $100-$1000
Packaging Details: Naked/Pallet
Delivery Time: 7-15DAYS
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 99/DAY
Detailed Product Description
Color: Black,Blue,Black/As Requirements,Black/White Or Any Color Material: Natural Rubber,EPDM,SBR,SILICONE,EVA
Application: STD,STS,Ships And Boats,Ship Fender,Marine/quay/dock/boat Warranty Period: 3 Years
Type: DO,Pneumatic,D,UV-protection Packing: Normal Packing,Nude Packing/As Requirement,Standard Package
Diameter: 0.5m-3.3m Certification: CCS BV Certification ISO17357 ISO9001,ABS,DNV,LR,CCS
Usage: Pneumatic Marine Fenders Cone Fender,Protects Ship During Ship-to-ship Operations Or Mooring At Quay,Protect Boat Length: 0.5m~12.0m
Chain: Hot Galvanizing Or Stainless Steel(304 Quality: Excellent
Design Using Life: 10 Years Feature: Aging Resistance
High Light:

Pneumatic Rubber Fender ISO 17357

,

Floating Pneumatic Rubber Fender 80KPA

,

ISO 17357 Yokohama Type Marine Fender

ISO 17357 Floating Rubber Yokohama Type Marine Fender Pneumatic Rubber Fender



1. Pneumatic rubber fender introduction

Inflatable rubber fender is a kind of ship berthing, buffer and protection equipment. It uses compressed air as a buffer medium to prevent collisions when ships are berthing. Pneumatic rubber fenders are more economical and durable than ordinary rubber fenders, so they are more popular and widely used.



Easy installation and great protection effect.



Pneumatic rubber fender is the world's leading anti-collision device for ships. It has become an ideal ship protection medium widely used in large oil tankers, LPG ships, offshore platforms, large piers, ports and piers.

ISO 17357 Floating Pneumatic Rubber Fender Yokohama Type Marine Fender 0





2. Pneumatic rubber fender Parameter



Pneumatic 80 fender size and performance requirements

Nominal size diameter x length

mm

Initial internal pressure

kPa

Guaranteed energy absorption (GEA) Reaction force at GEA deflection (R) Hull pressure (Internal pressure) at GEA deflection (P)
Minimum value at deflection 60±5% kJ Tolerance±10% kN

Reference value

kPa

500 x 1000 80 8 85 174
600 x 1000 80 11 98 166
700 x 1500 80 24 180 177
1000 x 1500 80 45 239 160
1000 x2000 80 63 338 174
1200 x 2000 80 88 390 166
1350 x 2500 80 142 561 170
1500 x 3000 80 214 761 174
1700 x 3000 80 267 840 168
2000 x 3500 80 430 1150 168
2500 x 4000 80 925 1815 180
2500 x 5500 80 1317 2653 195
3300 x 4500 80 1640 2476 171
3300 x 6500 80 2532 3961 191
3300 x 10600 80 4281 6907 208
4500 x 9000 80 6633 7551 192
4500 x 12000 80 9037 10490



202







































































ISO 17357 Floating Pneumatic Rubber Fender Yokohama Type Marine Fender 1





3. Pneumatic Rubber Fender Features

The development of "Yokohama Pneumatic Inflatable Rubber Fender" is closely related to the advancement and development of ship technology. It is necessary to continuously deal with VLCC, ULCC, large gas carriers, bulk carriers and other increasingly larger tankers Carrier and floating structure.



The protection performance of this fender is better.



Floating pneumatic fenders are used worldwide
Ship-to-ship (STS) transshipment operations, docks and various ships.

ISO 17357 Floating Pneumatic Rubber Fender Yokohama Type Marine Fender 2

4. Pneumatic Rubber Fender Application

Pneumatic rubber fenders are suitable for many applications, including:
1. Oil tankers, gas carriers and bulk carriers;
2. Fast ferries and aluminum-hulled ships;
3. Temporary permanent installation;
4. Quick response and emergency protection;
5. As an out-of-zone fender for re-adjusting ships and shore facilities.
6. Marine vessel operations, etc.

ISO 17357 Floating Pneumatic Rubber Fender Yokohama Type Marine Fender 3



5. After-sale service

Quality is the cornerstone and service is the soul.



With a complete technical support system and meticulous after-sales service, we continue to provide customers with stable and reliable pneumatic rubber fenders, and win the trust and satisfaction of customers.





Actively meet the requirements of all customers and suppliers at home and abroad.



Qingdao Henger Marine Shipping Supplies Co., Ltd. which provides the following services to all customers.



1. 24-hour real-time online technical consultation and support.

2. 24-month warranty period (without any man-made damage), free maintenance service during the warranty period.

3. Lifetime maintenance service.

ISO 17357 Floating Pneumatic Rubber Fender Yokohama Type Marine Fender 4



6. FAQ

Q: What is the material of your pneumatic fender products?
A: The main raw materials are natural rubber, synthetic tire cord and customized hardware.



Q: Are you a factory or a trading company?
A: We are a manufacturing plant located in Jimo District, Qingdao City, one hour's drive from Qingdao Port and 40 minutes' drive from Qingdao Airport, with convenient transportation and logistics.



Q: Do you provide OEM services?
A: Yes,the OEM and ODM are acceptable.



Q: What are the delivery time and payment terms?
A: The delivery time depends on the product model and the order quantity. Usually about 7-15 working days.
Payment can be made by T/T, L/C, Western Union, Paypal, etc.
