Cost-effective Marine Pneumatic Rubber Fender With Perfect Craftsmanship

Key Attributes
Brand Name: Henger
Model Number: HE0013
Place of Origin: China
Certification: ISO17357、Iso 9001、BV、ccs、LR、DNV
Minimum Order Quantity: 1 Pcs
Supply Ability: 50/week
Delivery Time: 7-14days
Payment Terms: D/A, D/P, L/C, T/T, Western Union,
Standard Packaging: Nacked/In case

Product Summary

Cost-effective Marine Pneumatic Rubber Fender With Perfect Craftsmanship 1. Pneumatic rubber fender introduction 1 Outer rubber The outer rubber layers that covers the outside of fender protects the cord layers and the inner rubber from abrasion and other external forces. This compound has ...

Product Custom Attributes

Highlight

Marine Pneumatic Rubber Fender

,

Pneumatic Rubber Fender with Craftsmanship

,

Craftsmanship marine rubber fender

Material:
Rubber
Size:
Customized Size
Color:
Customized Color
Warranty Period:
24 Months
Packing:
Nude/In Cases
Certification:
CCS BV Certification ISO17357 ISO9001,LR,CCS
Product Description

Cost-effective Marine Pneumatic Rubber Fender With Perfect Craftsmanship



1. Pneumatic rubber fender introduction



1 Outer rubber

The outer rubber layers that covers the outside of fender protects the cord layers and the inner rubber from abrasion and other external forces. This compound has sufficient tensile and tear strength to withstand any weather condition and hard usage. Standard color is black, but other colors are available on request.



2 Inner rubber

The liner of a rubber membrane seals the pressurized air inside the fenders.





3 Synthetic tire cord layers for reinforcement

The reinforcement layers, which are made of synthetic tire cord commonly used in tires, are arranged at ideal angles to hold the internal pressure and to distribute the stress evenly providing strong efficient reinforcement.



4 Beading ring

A steel ring is placed at one end (or both ends) of the fender and holds the end of cord layers.



5 Flange

A steel flange is mounted on the fender, to which an air valve or safety valve can be adapted.



6 Safety valve

Fenders of diameter 2500mm and larger shall be equipped with safety valve for releasing excess internal pressure when the fenders are over-compressed accidentally. Fender which are smaller than 2500mm in diameter, can be equipped with a safety valve if required.



7 Metal accessories

All the relevant metal accessories of pneumatic fenders, include shackles, towing rings, swivels, chain net, are made of stainless steel, which are resistant for sea water corrosion.


Cost-effective Marine Pneumatic Rubber Fender With Perfect Craftsmanship

2. Pneumatic rubber fender Parameter



Pneumatic 80 fender size and performance requirements

Nominal size diameter x length

mm

Initial internal pressure

kPa

Guaranteed energy absorption (GEA) Reaction force at GEA deflection (R) Hull pressure (Internal pressure) at GEA deflection (P)
Minimum value at deflection 60±5% kJ Tolerance±10% kN

Reference value

kPa

500 x 1000 80 8 85 174
600 x 1000 80 11 98 166
700 x 1500 80 24 180 177
1000 x 1500 80 45 239 160
1000 x2000 80 63 338 174
1200 x 2000 80 88 390 166
1350 x 2500 80 142 561 170
1500 x 3000 80 214 761 174
1700 x 3000 80 267 840 168
2000 x 3500 80 430 1150 168
2500 x 4000 80 925 1815 180
2500 x 5500 80 1317 2653 195
3300 x 4500 80 1640 2476 171
3300 x 6500 80 2532 3961 191
3300 x 10600 80 4281 6907 208
4500 x 9000 80 6633 7551 192
4500 x 12000 80 9037 10490 202

Cost-effective Marine Pneumatic Rubber Fender With Perfect Craftsmanship

3. Pneumatic Rubber Fender Features

  • Meet the requirements of ISO17357:2002
    2. More secure and reliable
    3. Smaller parking force
    4. Adapt to the tide
    5 Low maintenance costs
    6. Low reactivity and Hull pressure
    7. The most cost-effective system
    8. Advantages of reducing shear force
    9. Simple installation and low cost
    10. There are many optional accessories.

4. Pneumatic Rubber Fender Transportation

Transportation We can take the deflation pallet transportation and the entire fender transportation without deflation according to the requirements of customers. We always put the customer's requirements first.

Cost-effective Marine Pneumatic Rubber Fender With Perfect Craftsmanship

5. After-sale service

Quality is the cornerstone, service is the soul.

We continue to provide our customers with stable & reliable quality pneumatic rubber fenders with a comprehensive system of technical support, meticulous and thoughtful after-sales service to win customers trust and satisfaction.



Qingdao Henger Shipping Supplies Co., Ltd provides following services to all customers.

1. 24 hours instant online technical consultation and support.

2. 24 months warranty period(without any artificial damage) and free repairing service within warranty period.

3. lifetime reparing service.

Cost-effective Marine Pneumatic Rubber Fender With Perfect Craftsmanship

6. FAQ

Q: What’s the material of your pneumatic fender products ?
A: the main raw materials are natural rubber, synthetic-tyre-cord fabric and customized hardwares, etc.


Q: Are you factory or trading company ?
A: We are manufacturing factory, located in Jimo district,Qingdao city, 1 hour drive to Qingdao port and 40 minutes drive to Qingdao airport, which is convenient in transportation logistics.


Q: Is OEM service available ?
A: yes
