Pneumatic Natural Marine Yokohama Rubber Fender 500 x 1000 600 x 1000

Key Attributes
Brand Name: Henger
Model Number: D2.0M*L3.5M
Place of Origin: China
Certification: CCS.BV.ISO
Minimum Order Quantity: 1
Supply Ability: 30 per week
Delivery Time: About 10 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Standard Packaging: Nude packing

Product Summary

Top Quality Pneumatic Natural Marine Rubber Yokohama Fenders For Sale Yokohama Floating Fender Features: 1. Ensure product energy absorption 2. Chain tire net floating pneumatic rubber fender and sling type fender 3. Thick structure of the skin on the surface of the product 4. Good angle performance ...

Product Custom Attributes

Highlight

500 X 1000 Yokohama Rubber Fender

,

600 X 1000 Yokohama Rubber Fender

,

500 X 1000 pneumatic rubber fender

Product Name:
Pneumatic Rubber Fender
Brand:
Henger
Material:
Natural Rubber
Size:
D2.0M*L3.5M
Certificate:
CCS.BV.ISO
Warranty:
2 Years
Usage:
Protect Boat
Packing:
Pallet
Product Description





Top Quality Pneumatic Natural Marine Rubber Yokohama Fenders For Sale




Yokohama Floating Fender Features:



1. Ensure product energy absorption



2. Chain tire net floating pneumatic rubber fender and sling type fender



3. Thick structure of the skin on the surface of the product



4. Good angle performance of the product



5. the deflatable pneumatic fender can reduce the surface pressure on the side wall of the ship. (The ability to withstand the surface pressure of the fender is as high as 14 tons/m²).



6. The fender will not reduce the compression performance when it is impacted and tilted.



7. Pneumatic Floating Rubber Fender is suitable for cold weather, because compressed air can be used as a buffer medium.



8. The floating pneumatic rubber fender is suitable for areas with large or small tides.



9. Especially in the mooring and lighters of large ships at sea piers.



  • The fender can keep a large gap between the hull and the structure



Pneumatic Natural Marine Yokohama Rubber Fender 500 x 1000 600 x 1000 0





The following are the product specifications and detailed parameters:





Pneumatic 50 fender size and performance requirements

Nominal size diameter x length

mm

Initial internal pressure

kPa

Guaranteed energy absorption (GEA) Reaction force at GEA deflection(R) Hull pressure (Internal pressure) at GEA deflection (P)
Minimum value at deflection 60±5% kJ Tolerance±10 % kN

Reference value

kPa

500 x 1000 50 6 64 132
600 x 1000 50 8 74 126
700 x 1500 50 17 137 135
1000 x 1500 50 32 182 122
1000 x 2000 50 45 257 132
1200 x2000 50 63 297 126
1350 x 2500 50 102 427 130
1500 x 3000 50 153 579 132
1700 x 3000 50 191 639 128
2000 x 3500 50 308 875 128
2500 x 4000 50 663 1381 137
2500 x5500 50 943 2019 148
3300 x 4500 50 1175 1884 130
3300 x 6500 50 1814 3015 146
3300 x 10600 50 3067 5257 158
4500 x 9000 50 4752 5747 146
4500 x 12000 50 6473 7984 154





Pneumatic 80 fender size and performance requirements

Nominal size diameter x length

mm

Initial internal pressure

kPa

Guaranteed energy absorption (GEA) Reaction force at GEA deflection (R) Hull pressure (Internal pressure) at GEA deflection (P)
Minimum value at deflection 60±5% kJ Tolerance±10% kN

Reference value

kPa

500 x 1000 80 8 85 174
600 x 1000 80 11 98 166
700 x 1500 80 24 180 177
1000 x 1500 80 45 239 160
1000 x2000 80 63 338 174
1200 x 2000 80 88 390 166
1350 x 2500 80 142 561 170
1500 x 3000 80 214 761 174
1700 x 3000 80 267 840 168
2000 x 3500 80 430 1150 168
2500 x 4000 80 925 1815 180
2500 x 5500 80 1317 2653 195
3300 x 4500 80 1640 2476 171
3300 x 6500 80 2532 3961 191
3300 x 10600 80 4281 6907 208
4500 x 9000 80 6633 7551 192
4500 x 12000 80 9037 10490 202



Advantages of Qingdao Hunger marine inflatable fenders:

1. The rubber marine fenders warranty period can be up to 24 months

2. The rubber used for the fender has passed SGS certification and is the best rubber on the market. It is wear-resistant and not easily broken.

3. Yokohama Dock Rubber Fender can pass the certification of major classification societies and fully comply with the ISO17357-2014 standard.

4. We have a professional service team, which can save you communication time



Pneumatic Natural Marine Yokohama Rubber Fender 500 x 1000 600 x 1000 1



QINGDAO HENGER SHIPPING SUPPLIES CO.,LTD



Rubber Marine Fenders is widely used in ship-to-ship (STS) transshipment operations, terminals and various ships worldwide.



Since its establishment, Henger has provided more than 20,000 fenders for ship-to-ship and ship-to-dock operations serving our important customers worldwide. These fenders are used in the safe operation of ship mooring and mooring. Plays a vital role.



Technical advantages
Qingdao Henger inflatable fender has introduced the latest Yokohama Floating Fender production technology from Yokohama, Japan, and hired experienced engineers at home and abroad for training and guidance throughout the year. "Floating inflatable rubber fender" is produced according to international quality standards.


Production advantages
Qingdao Henger has accumulated 20 years of professional rubber product production experience. It is an excellent company in the region, with strong technology and capital, and is a supplier of stable quality marine fenders and government marine supplies.



Pneumatic Natural Marine Yokohama Rubber Fender 500 x 1000 600 x 1000 2



Operational use of fender:

For ship-to-ship operations of light ships, two contact points are sufficient. However, for ship operations of large ships, 1-2 fenders of the same specification must be used in addition to ensure safety. Inflatable rubber fenders can be used as the main protection system to absorb ship-to-ship energy while keeping the two ships at a certain distance.

In addition, a small inflatable rubber fender can be hung on the side of the ship as an auxiliary protection. Inflatable rubber fenders require chains and ropes to be hung from the ship or dock, and their specifications are selected according to the size and use environment of the fender.



Service and transportation:


The product warranty period of Henger is 24 months, and the average supplier can not reach such a long time, which is also the trust we and customers have in our factory products.


After-sales service we are online 24 hours a day, as long as you have questions we will always be there, there will be professional staff to answer your questions and provide you with technical support.


Transportation We can take the deflation pallet transportation and the entire fender transportation without deflation according to the requirements of customers. We always put the customer's requirements first.





Thank you for reading. If you have any needs and interests, you can contact me.
