High-Quality Marine Rubber Airbag with 4-12 Layer Construction Heavy-Duty Marine Rubber Airbag Made From Synthetic Tire Cord High-performance marine rubber airbags constructed from durable synthetic tire cord, designed for demanding marine applications. Product Specifications Attribute Value ...
| Attribute | Value |
|---|---|
| Application | Salvaging, Ship Launching And Ashoring, Cargo Carrying |
| Condition | New |
| Transport Package | Pallet |
| Material | Rubber |
| Diameter | 0.8-3 M |
| Length | 4-25 M |
Located in Qingdao, a beautiful coastal city, Qingdao Henger Shipping Supplies Co., Ltd is a high-tech enterprise specializing in manufacturing marine products including marine rubber fenders, marine airbags, navigation marks, and marine buoys. All products are ISO 9001-2008 certified and have IACS quality authentication from CCS, BV, GL, ABS, and LG.
With strong technological capabilities, advanced manufacturing techniques, and complete facilities, we are committed to becoming a top-ranking international marine products manufacturer, providing high-quality products and excellent service while ensuring global marine safety through worldwide cooperation.
Marine Rubber Airbags are innovative products with independent intellectual property rights in China. They are primarily used for ship launching and landing, weight lifting, handling, and underwater buoyancy aid installation. These airbags are widely used worldwide due to their space efficiency, elimination of large mechanical equipment needs, time-saving benefits, and cost-effectiveness. Through years of development, marine rubber airbags have become safer, more effective, and environmentally friendly.
| Diameter(m) | Medium Pressure (4-5) | High Pressure (6-8) | ||
|---|---|---|---|---|
| Test Pressure | Working Pressure | Test Pressure | Working Pressure | |
| 1.0 | 0.14-0.16 | 0.12-0.14 | 0.22-0.26 | 0.20-0.24 |
| 1.2 | 0.12-0.14 | 0.10-0.12 | 0.20-0.24 | 0.17-0.22 |
| 1.5 | 0.10-0.12 | 0.08-0.10 | 0.15-0.20 | 0.13-0.18 |
| 1.8 | 0.08-0.10 | 0.07-0.09 | 0.13-0.16 | 0.11-0.14 |
| 2.0 | 0.07-0.09 | 0.06-0.08 | 0.12-0.15 | 0.10-0.13 |
| Diameter(m) | Effective Length(m) | Layer | Pressure(MPa) |
|---|---|---|---|
| 1.0 | 10 | 5~6 | 0.07~0.10 |
| 1.0 | 12 | 5~6 | 0.07~0.10 |
| 1.0 | 15 | 5~6 | 0.07~0.10 |
| 1.2 | 10 | 5~6 | 0.08~0.12 |
| 1.2 | 12 | 5~6 | 0.08~0.12 |
| 1.2 | 15 | 5~6 | 0.08~0.12 |
| 1.5 | 12 | 5~8 | 0.08~0.16 |
| 1.5 | 15 | 5~8 | 0.08~0.16 |
| 1.5 | 18 | 5~8 | 0.08~0.16 |
| 1.5 | 20 | 4~8 | 0.08~0.16 |
| 1.5 | 24 | 5~8 | 0.08~0.16 |
| 1.8 | 12 | 5~8 | 0.08~0.15 |
| 1.8 | 15 | 5~8 | 0.08~0.15 |
| 1.8 | 18 | 5~8 | 0.08~0.15 |
| 1.8 | 20 | 5~8 | 0.08~0.15 |
| 1.8 | 24 | 5~8 | 0.08~0.15 |
| 2.0 | 18 | 6~10 | 0.08~0.18 |
| 2.0 | 20 | 6~10 | 0.08~0.18 |
| 2.0 | 24 | 6~10 | 0.08~0.18 |
| 2.5 | 18 | 7~10 | 0.07~0.13 |
| 2.5 | 20 | 7~10 | 0.07~0.13 |
| 2.5 | 24 | 7~10 | 0.07~0.13 |
With over two decades of successful application in China, marine rubber airbags have established themselves as the most reliable solution for ship launching and upgrading operations. This technology handles vessels from small-tonnage boats to massive ships weighing tens of thousands of tons. Internationally recognized, our airbag technology has gained acceptance among dockyards, shipyards, and port construction companies worldwide, particularly in North America, Europe, and Southeast Asia.
Marine rubber fenders serve as efficient solutions for port construction applications including caisson lifting, launching, relocation, and transportation operations. Their robust design and exceptional load-bearing capacity make them ideal for demanding marine construction projects.
With superior buoyancy characteristics and impressive load-bearing capacity, marine rubber airbags have become essential tools for sunken vessel salvage operations and buoyancy aid applications, providing reliable performance in challenging marine environments.
