High Quality Pneumatic Rubber Fender with BV Certificate for Marine
About Qingdao Henger Shipping Supplies Co., Ltd
Located in Qingdao, a beautiful coastal city, Qingdao Henger Shipping Supplies Co., Ltd is a high-tech enterprise specializing in manufacturing marine products including marine rubber fenders, marine airbags, navigation marks, and marine buoys. All products are certified with ISO 9001-2008 and IACS quality authentication from CCS, BV, GL, ABS, LG, etc.
Inflatable Rubber Fender Introduction
The "Yokohama Type Inflatable Rubber Fender" was developed in 1958. Progress in the development of such floating inflatable rubber fenders is closely related to the progress and development of ship technology, and has to continuously cope with progressively larger oil tankers such as VLCC's, ULCC's, large gas carriers, bulk carriers and floating structures.
Floating Inflatable Fenders are used worldwide for ship-to-ship (STS) transfer operations, terminals, and for all kinds of ships. Since its creation until today, more than millions of fenders have been supplied worldwide both for ship-to-ship and ship-to-dock (STD) operations serving our valuable customers. These fenders play a critical role in the safe operation of ship berthing and mooring.
Product Features
- Constructed of several layers of strong tire-cord for pressure and cutting resistance
- Safety factor based on accepted theory and proven by extensive experimentation
- Large-size fenders equipped with safety valve for accidental over-pressure release
- Provides completely uniform surface pressure on contact
- Popular at LNG-ship terminals due to low and uniform surface pressure properties
- Improved manufacturing technique and raw material formula for kneading-resistance
- Each layer painted with specially formulated mucilage for dust & impurities dissolution
- Enhanced adhesiveness among layers to guarantee air tightness
Technical Specifications
| Fender Size |
Compression Amount (60%) |
Noumenon Weight (Kg) |
Weight with Protective Jacket (Kg) |
| D (mm) |
L (mm) |
Reaction (KN) |
Energy Absorption (KNm) |
| 500 | 1000 | 64 | 6 | 23 | 35 |
| 600 | 1000 | 74 | 8 | 28 | 40 |
| 700 | 1000 | 137 | 17 | 58 | 52 |
| 1000 | 1500 | 182 | 32 | 82 | 100 |
| 1000 | 2000 | 257 | 45 | 148 | 152 |
| 1200 | 2000 | 297 | 63 | 167 | 200 |
| 1350 | 2500 | 427 | 102 | 220 | 298 |
| 1500 | 2500 | 499 | 134 | 270 | 300 |
| 1500 | 3000 | 579 | 153 | 318 | 450 |
| 1700 | 3000 | 639 | 191 | 380 | 482 |
| 2000 | 3500 | 875 | 308 | 580 | 890 |
| 2000 | 4000 | 1000 | 352 | 680 | 1000 |
| 2500 | 4000 | 1381 | 663 | 1064 | 1180 |
| 2500 | 5500 | 2019 | 1131 | 1268 | 1380 |
| 3000 | 5000 | 2422 | 1357 | 1980 | 2388 |
| 3000 | 6000 | 2906 | 1293 | 2400 | 2690 |
| 3300 | 4500 | 1884 | 1175 | 2380 | 2617 |
Frequently Asked Questions
"I have ships but don't know how to choose the size of Factory Price Rubber Inflatable Floating Pontoon for Ship Lanching Made in China?
Don't worry. We have more than 20 years' experience. Please tell us information about your ship, we can suggest suitable size for you.
"What's your MOQ?"
Our MOQ is 1PC.
"What's your warranty period?"
Our warranty period is 2 years. We will be responsible for the repairment or replacement of new ones for you if it proved to be our quality problem.
