4-12 Layers Rubber Airbag Ship / Boat Launching Shipyard Docking

4-12 Layers Rubber Airbag Ship / Boat Launching Shipyard Docking

MOQ: 1
Price: $360
Standard Packaging: Pallet
Delivery Period: 5-8 work days
Payment Method: MoneyGram,Western Union,T/T,D/P,D/A,L/C
Supply Capacity: 5 Pieces/Day
Detail Information
Place of Origin
China
Brand Name
Henger
Certification
BV,CCS,DNV,LR,ABS
Model Number
MRA
Material:
Rubber With Synthetic Tire Cord
Diameter:
0.8-3 M
Length:
4-25 M
Application:
Salvaging, Ship Launching And Ashoring, Cargo Carrying
Repair Kit:
Available
Customized:
Customized
Standard:
ISO14409
Layer:
4-12 Layers
Highlight:

Boat Launching Rubber Airbag

,

Shipyard Docking Rubber Airbag

,

4-12 Layers Rubber Airbag

Product Description

1.Qingdao Henger Shipping Supplies Co., Ltd



Lies in Qingdao, a beautiful coastal city with red tiling and green trees, blue sea and clear sky, Qingdao Henger Shipping Supplies Co., Ltd is a high-tech enterprise integrated with manufacturing, research and innovation, technical services, specialized in manufacturing marine products, such as marine rubber fender, marine airbag, navigation mark and marine buoy. All products get ISO 9001-2008 certificate and IACS quality authentication from CCS, BV, GL, ABS, LG, etc.



4-12 Layers Rubber Airbag Ship / Boat Launching Shipyard Docking 0



With strong technology base, advanced manufacturing technique, complete manufacturing facilities and well-equipped checkout equipment, Qingdao Henger Marine Supplies Co., Ltd is devoted to forge itself into a top-ranking international competitive marine products manufacturer providing high quality products and perfect service for all customers, and shoulder the responsibility of ensuring global marine safety via mutually beneficial cooperation with friends all over the world.



4-12 Layers Rubber Airbag Ship / Boat Launching Shipyard Docking 1



2.Marine Rubber Airbags

Marine Rubber Airbag is China independent intellectual property rights of innovative products, the products are mainly applied to ship launching and landing, weight lifting, handling, installation of underwater buoyancy aid etc. Nowadays, Marine rubber airbags are widely used in the world. The Products are less limited by space, no large mechanical equipment, can shorten the working period and save the unnecessary cost. Through years of development practice, marine rubber airbag is become more safety, effective and green environmental protection.



4-12 Layers Rubber Airbag Ship / Boat Launching Shipyard Docking 2

4-12 Layers Rubber Airbag Ship / Boat Launching Shipyard Docking 3



3.Technical Requirement



According to CB/T 3795--1996, marine rubber fender should meet the following requirements.

1. Dimensional Deviation:

Diameter & Effective Length Deviation: ±2%

Total Length Deviation: ±4%

2. Amount of Elastic Deformation: diameter deformation amount ≤ 5% under 1.2 times working pressure.

3. Safety Factor: >4.5

4. Air Tightness: depressurization < 5% after 1hour inflation

5. Surface Quality: fairing line shape, no crack, no bubble, no double skin, no impurities, no distinct dirt and other apparent defect.

6. Anti-explosion design of end part.



4-12 Layers Rubber Airbag Ship / Boat Launching Shipyard Docking 4

4-12 Layers Rubber Airbag Ship / Boat Launching Shipyard Docking 5

4-12 Layers Rubber Airbag Ship / Boat Launching Shipyard Docking 6

4-12 Layers Rubber Airbag Ship / Boat Launching Shipyard Docking 7



4.Specifications

Diameter(m)

1.0

1.2

1.5

1.8

2.0

Medium Pressure
(4-5)

Test Pressure

0.14-0.16

0.12-0.14

0.10-0.12

0.08-0.10

0.07-0.09

Working Pressure

0.12-0.14

0.10-0.12

0.08-0.10

0.07-0.09

0.06-0.08

High Pressure
(6-8)

Test Pressure

0.22-0.26

0.20-0.24

0.15-0.20

0.13-0.16

0.12-0.15

Working Pressure

0.20-0.24

0.17-0.22

0.13-0.18

0.11-0.14

0.10-0.13



 Some normal sizes of our Marine Rubber Airbag, customized sizes are also available



Diameter(m)

Effective Length(m)

Layer

Pressure(MPa)

1.0

10

5~6

0.07~0.10

1.0

12

5~6

0.07~0.10

1.0

15

5~6

0.07~0.10

1.2

10

5~6

0.08~0.12

1.2

12

5~6

0.08~0.12

1.2

15

5~6

0.08~0.12

1.5

12

5~8

0.08~0.16

1.5

15

5~8

0.08~0.16

1.5

18

5~8

0.08~0.16

1.5

20

4~8

0.08~0.16

1.5

24

5~8

0.08~0.16

1.8

12

5~8

0.08~0.15

1.8

15

5~8

0.08~0.15

1.8

18

5~8

0.08~0.15

1.8

20

5~8

0.08~0.15

1.8

24

5~8

0.08~0.15

2.0

18

6~10

0.08~0.18

2.0

20

6~10

0.08~0.18

2.0

24

6~10

0.08~0.18

2.5

18

7~10

0.07~0.13

2.5

20

7~10

0.07~0.13

2.5

24

7~10

0.07~0.13



5.Marine Rubber Airbag Application



 4.1. Ship Launching & Upgrading

With more than 20 years development in China, marine rubber airbag is proved to be the most reliable and stable technique for ship launching & upgrading. It is applicable from tons of flat board to ten thousand tons of huge ship. Meanwhile, marine rubber airbag is also widely acknowledged by foreign dockyards, shipyards, port/harbour construction companies. Ship launching & upgrading technique with marine rubber airbag is also highly promoted in the markets, such as America, Europe, Southeast Asia.



4.2. Weight Lifting & Moving

Marine rubber fend could be applied to caisson lifting, launching, moving and transporting in port constructing projects



4.3. Buoyancy Aid & Salvage

Because marine rubber airbag has buoyancy force and load-bearing capacity, it is also widely used in sunken vessel salvage and Buoyancy Aid.



4-12 Layers Rubber Airbag Ship / Boat Launching Shipyard Docking 8

4-12 Layers Rubber Airbag Ship / Boat Launching Shipyard Docking 9
