Cone Type Marine Ship Rubber Fender Pad, Cone Boat Rubber Fender

Cone Shape Solid Dock Rubber Fender Marine Fender

Cone fender is the third generation of the cell rubber fender, and recommended for all

types of applications, including high tidal variation sites. They are known for their optimum performance, better efficiency, higher stability and performance under shear and compression loads.

Cone rubber fenders adopt the new structure design of cone rubber body and front steel frame, make the fender in the reaction under the condition of no increase, the design compression deformation increased from 52.5% to 70%, its emergence, can make the dock structure light-duty design and reduce the project cost, is an ideal alternative to the cell rubber fender. Besides, the installation of an facing pad (PE) in front of the front panel can reduce the friction coefficient between the ship and the fender, and greatly reduce the shear force (horizontal force) generated by the fender when the ship is berthing, thereby increasing fender life.

It has been ten years since the cone rubber fender came into being. The design of cone rubber fenders has become a new trend in wharf design and represents the new level of wharf fender design.

1. Big deflection, high performance.

2. Large panels supporting.The equipped steel frontal panel can greatly reduce the hull pressure, which makes it specially proper for the berthing of large ship.

3. Maintain performance under angular (10 degree Max.) berthing.

4. Wide range sizes, can meet multi-design requirements.

5. UHMW-PE shield bolted on the steel frontal panel can lessen the friction factor between ship and fender system and reduce the shear force caused during ship berthing therefore prolong the fender system service life.

6. Special for the ports which request low reaction force and high energy absorption or all the ports suitable for super cell fender system, it gets various install methods and easy for installation.

And all of our cone rubber fenders can be inspected and tested by clients or the third party, like CCS, DNV, ABS, LR, BV, SGS and etc. Only part of the certificates are shown here. We guarantee that all products are deliveres after strict inspection.

Q: I only need one. Can you produce it?

A: First of all, if what you need is our standard size product, we can produce it for you when we produce other products of the same size. Secondly, if you need non-standard products, we can customize them according to your requirements. But considering the cost of production and transportation, we suggest you refer to our standard specifications.

Q: Can we put our logo or company name on your products?

A: Of course, we can design the logo for you or mark the logo on the product according to your requirements.

Q: Our parent company is in the Malaysia, but our projects are in other places. Will you have any logistic problems in processing the order?

A: We have a professional logistics team, which can perfectly solve your transportation problems and timely give you tracking feedback on logistics.
