| Certification: | CCS BV Certification ISO17357 ISO9001 | Product Name: | Sling Type Solid Foam Filled Fender And Cylindrical Eva Foam Filled Fender |
|---|---|---|---|
| Brand: | HENGER | Inner Material: | EVA Foam |
| Material: | Polyourethane Foam,Polyurethane,EVA,Natual Rubber,High Density EVA | Size: | Customized Size,as Per Customer's Request,according To Customer Required,one /two/three Steel Wire,any Sizes According To Your Boats' Size |
| Warranty Period: | 12 Months | Part: | Foam Filled Fender,marine Foam Fender PVC Fender,swivel,Marine Fender,Other |
| Color: | Black,Customers' Requirments,Red,Orange,blue | Type: | Inflatable Boat Fender,foam,pvc Fender,Yokohama-type,foam Boat Fenders |
| Usage: | Collision Avoidance,to Protect Boats When Docking,mooring And Berthing,protect Ship Board Etc,Protect Boat | Expected Life Span: | 10-15 Years,More Than 15 Years |
| High Light: | Solid Foam Filled Marine Fenders,Sling Type Foam Filled Marine Fenders,Cylindrical Eva Foam Filled Fender |
||
Foam Filled Fender
Henger products all accepet quality check and fresh sample. Foam filled fender,also called EVA solid fender, is a new type fender using light weight high elasticity foam as cushion medium, widely applied to harbour, offshore,STS and STD operation.Henger Foam Filled Solid Fender is made of environmental protection material and high elasticity polymeric material. long service life and high economic value of this product is achieved by the high quality material with performance of high strength, high elasticity, high adhesion, anti-leakage,and aging resistance.
Inside of Foam Filled Solid Fender is filled with environmental protection material-EVA with coating protective layer of polyurea material on outer surface. Polyurea is an new material of adjustable high-elasticity modulus. There are galvanized flange and swivel on the fender two ends. Like pneumatic rubber fender, tyre-chain net protective jacket
a. Keep same and nothing broken after 50tons pressing machine press and recover same very quickly;
b.Shape, color and logo could be customized according to customers' requirement.
Foam Filled EVA Polyurethane Floating Marine Ship Fenders for Boat/Dock
- Can as float rod on the sea
- Ultra-tough, unsinkable design
- Remains fully functional even if skin is punctured
- Colorful
- Flexible,cost-saving
- Easy to install,move and use. Low maintenance.
3. Features of our foam filled fenders
Our products Fully compliant with ISO 9001 standard, and colors are customized.
Diameters ranging from 300 mm to 4500 mm and length ranging from 500 mm to 900 mm.
Constructed with fender buffer, Steel Bar, Suspending Ring, Closed Cell foam and flange.Easy for installation and maintenace. Applicable for pier and dock with high tide difference, or between ships and emergency purpose. PLT-PF foam fender get good floating character and free from tide difference so the fender can be kept at ideal waterline.
| Model |
D (mm) |
L (mm) |
Compression 60% | Reference Weight(kg) | |
| Counter-force(KN) |
Energy Absorption (KJ) |
||||
| Ø 500×1000L | 500 | 1000 | 71 | 8 | 34 |
| Ø 600×1000L | 600 | 1000 | 86 | 12 | 45 |
| Ø 700×1500L | 700 | 1500 | 161 | 27 | 101 |
| Ø 1000×1500L | 1000 | 1500 | 205 | 49 | 206 |
| Ø 1000×2000L | 1000 | 2000 | 274 | 64 | 275 |
| Ø 1200×2000L | 1200 | 2000 | 337 | 93 | 405 |
| Ø 1200×2400L | 1200 | 2400 | 390 | 110 | 475 |
| Ø 1350×2500L | 1350 | 2500 | 463 | 145 | 626 |
| Ø 1500×3000L | 1500 | 3000 | 624 | 216 | 927 |
| Ø 1700×3000L | 1700 | 3000 | 696 | 273 | 1191 |
| Ø 2000×3500L | 2000 | 3500 | 990 | 456 | 1923 |
| Ø 2000×4000L | 2000 | 4000 | 1110 | 505 | 2298 |
| Ø 2200×4500L | 2200 | 4500 | 1396 | 679 | 2992 |
| Ø 2500×4000L | 2500 | 4000 | 1386 | 781 | 3434 |
| Ø 2500×5000L | 2500 | 5000 | 1750 | 985 | 4272 |
| Ø 3000×5000L | 3000 | 5000 | 2050 | 1410 | 6411 |
| Ø 3000×6000L | 3000 | 6000 | 2460 | 1695 | 7293 |
| Ø 3300×6500L | 3300 | 6500 | 2950 | 2245 | 8335 |
| Ø 4500×9000L | 4500 | 9000 | 19650 | 7860 | 21460 |
if there is customizing size requirement, please kindly contact our sale service staff.
● High wear resistance which is 3-5times of nature rubber.
● Excellent oil resistance which is 4times of NBR.
● High mechanical strength.Its tensile intention and tear strength and burden capability are several times of common rubbers.
● Excellent tolerance of acid, alkali, low temperance and organic solvent.
● High metal-bonding performance.
● Wide hardness range from Shore A100 adjustable.
● Available in a variety of sizes , Diameters ranging from 500 mm to 4500 mm and length ranging from 500 mm to 12000 mm
● Installed on the wharf and dock for berthing
● Installed on the shipboard for berthing
● Float chamber
● For moving the cargo
● Gravity wharf and dolphin type quay
● Harbors,all kinds ofships
