Net Type Pneumatic Fender Pneumatic rubber fender is a device for berthing, buffering and protection of ships. It uses compressed air as a buffering medium to prevent ships from colliding when berthing, so as to reduce damage to ships. Description: Qingdao Henger Ship Supplies Co., Ltd. We are a ...
Pneumatic rubber fender is a device for berthing, buffering and protection of ships. It uses compressed air as a buffering medium to prevent ships from colliding when berthing, so as to reduce damage to ships.
Description:
Qingdao Henger Ship Supplies Co., Ltd.
We are a manufacturer of marine supplies, and our products involve many areas of marine use! The photo below is a product map of my company!
Because we are a manufacturer, our prices are very competitive!
Ship docking, ship launching, ship mooring, ship navigation, we can provide you with products in all fields. We are the largest production base in Qingdao. Our products are self-made and sold, and no third-party traders earn the difference!
If you want to work with us, please contact me!
My email address: tom-li@hengergroup.com
My WhatsApp: +86 15662503695
My WeChat: Lxc667381
Our company website: www.pneumaticrubberfenders.com
What Is Net type Pneumatic fender?
In 1958, the "Yokohama-type inflatable rubber fender" was developed. The development of this floating inflatable rubber fender is closely related to the progress and development of ship technology, and it must continue to respond to the needs of large oil tankers such as VLCC, ULCC and large gas carriers, bulk carriers and floating structures. Floating pneumatic fenders are widely used in ship-to-ship (STS) transshipment operations, terminals and various container ships worldwide. Since its establishment, it has provided more than millions of fenders for global shipboard and shipboard (STD) operations to provide services to our important customers. These fenders play a vital role in the safe operation of ship mooring and mooring.
Pneumatic rubber fender is a device for berthing, buffering and protection of ships. It uses compressed air as a buffering medium to prevent ships from colliding when berthing, so as to reduce damage to ships. Pneumatic rubber fenders are more economical and more durable than ordinary rubber fenders, so they are more popular and widely used.
Pneumatic rubber fender is a leading anti-collision device for maritime applications in the world today. It has become an ideal ship protection medium and has been widely used by large oil tankers, LPG ships, offshore platforms, large docks, ports and docks.
Net type Pneumatic fender Specification Table:
| Pneumatic 50 fender size and performance requirements | ||||
|
Nominal size diameter x length |
Initial internal pressure |
Guaranteed energy absorption (GEA) |
Reaction force at GEA deflection(R) |
Hull pressure (Internal pressure) at GEA deflection (P) |
|
Minimum value at deflection 60±5% kJ |
Tolerance±10 % kN | Reference value kPa |
||
| 500 x 1000 | 50 | 6 | 64 | 132 |
| 600 x 1000 | 50 | 8 | 74 | 126 |
| 700 x 1500 | 50 | 17 | 137 | 135 |
| 1000 x 1500 | 50 | 32 | 182 | 122 |
| 1000 x 2000 | 50 | 45 | 257 | 132 |
| 1200 x2000 | 50 | 63 | 297 | 126 |
| 1350 x 2500 | 50 | 102 | 427 | 130 |
| 1500 x 3000 | 50 | 153 | 579 | 132 |
| 1700 x 3000 | 50 | 191 | 639 | 128 |
| 2000 x 3500 | 50 | 308 | 875 | 128 |
| 2500 x 4000 | 50 | 663 | 1381 | 137 |
| 2500 x5500 | 50 | 943 | 2019 | 148 |
| 3300 x 4500 | 50 | 1175 | 1884 | 130 |
| 3300 x 6500 | 50 | 1814 | 3015 | 146 |
| 3300 x 10600 | 50 | 3067 | 5257 | 158 |
| 4500 x 9000 | 50 | 4752 | 5747 | 146 |
| 4500 x 12000 | 50 | 6473 | 7984 | 154 |
| Pneumatic 80 fender size and performance requirements | ||||
|
Nominal size diameter x length |
Initial internal pressure |
Guaranteed energy absorption (GEA) |
Reaction force at GEA deflection (R) |
Hull pressure (Internal pressure) at GEA deflection (P) |
|
Minimum value at deflection 60±5% kJ |
Tolerance±10% kN | Reference value kPa |
||
| 500 x 1000 | 80 | 8 | 85 | 174 |
| 600 x 1000 | 80 | 11 | 98 | 166 |
| 700 x 1500 | 80 | 24 | 180 | 177 |
| 1000 x 1500 | 80 | 45 | 239 | 160 |
| 1000 x2000 | 80 | 63 | 338 | 174 |
| 1200 x 2000 | 80 | 88 | 390 | 166 |
| 1350 x 2500 | 80 | 142 | 561 | 170 |
| 1500 x 3000 | 80 | 214 | 761 | 174 |
| 1700 x 3000 | 80 | 267 | 840 | 168 |
| 2000 x 3500 | 80 | 430 | 1150 | 168 |
| 2500 x 4000 | 80 | 925 | 1815 | 180 |
| 2500 x 5500 | 80 | 1317 | 2653 | 195 |
| 3300 x 4500 | 80 | 1640 | 2476 | 171 |
| 3300 x 6500 | 80 | 2532 | 3961 | 191 |
| 3300 x 10600 | 80 | 4281 | 6907 | 208 |
| 4500 x 9000 | 80 | 6633 | 7551 | 192 |
| 4500 x 12000 | 80 | 9037 | 10490 | 202 |
| Ship Tonnage(T) | Recommendation Size D x L ( m) | Ship Type |
| 50 | 0.5 x1.0 | Fishing ship |
| 100 | 0.7 x 1.5~1.0 x 1.5 | Fishing ship |
| 200 | 1.0 x 1.5~1.2 x 2.0 | Fishing ship, towing ship |
| 300-500 | 1.2 x 2.0~1.5 x 2.5 | Fishing ship, towing ship |
| 1000 | 1.5 x 2.5~1.5 x 3.0 | Towing ship, cargo ship |
| 3000 | 2.0 x 3.0~2.0 x 3.5 | cargo ship, ocean trawler |
| 10000 | 2.0 x 3.5~2.5 x 4.0 | cargo ship |
| For Small & Middle Size Ship | ||
Features of Net type Pneumatic fender:
*Henger company can provide various sizes, diameter from 500mm to 4500mm, length from 500mm to 12000mm
*Henger company can provide a variety of colors according to customer requirements, black, milky white, warship-grade gray, orange red, blue
*The fender is composed of an inner rubber layer, a reinforcing wire layer and an outer rubber layer
*The fender is fully tested for material and hydrostatic pressure irregularities before leaving the factory
*The angle and durability are correctly evaluated during the production process
*Can be customized for customers with all relevant signs
*The fender will carry the latest certification
Henger fenders provide services and guarantees:
The warranty period of Henger Yokohama rubber fender is 24 months, which also comes from the trust of customers in our factory's products.
After-sales service We are online 24 hours a day. As long as you have any questions, we will always be there. We will have professional staff to answer you and provide you with technical support.
Transportation According to customer requirements, we can carry out deflated pallet transportation, and small fenders do not need to be deflated for transportation. We always put the requirements of our customers first.
FAQ
Q: What’s the delivery time and payment terms ?
A: Delivery time is based on product model and order quantity. normally it is around 7-15 working days.
The payment could paid by T/T, L/C, Western Union, Paypal, etc.
