Pneumatic rubber fender with tire sheath type Tyre To Ship Protection 50KPa Or 80Kpa

1. Introduction of inflatable rubber fender

Inflatable fenders are widely used in large ships, yachts, ocean platforms, and harbor terminals. It uses compressed air as a buffer medium to absorb the impact energy of the ship. Therefore, compared with the general compressed rubber fender, it has large energy absorption, small reaction force, large contact area with the ship, and small unit surface pressure acting on the ship. , The performance is not reduced when tilted and compressed, and the installation is simple and convenient. It can be adapted to the docking of ships in all directions.

This type of inflatable ball is equipped with a sheath outside, which is composed of galvanized chains and tires crossing each other, which can effectively protect the ball. The chain is made of anti-corrosion hot-dip galvanized material, and is covered with a rubber tube to prevent the chain from wearing the surface of the ball.

The inflatable ball bearing of Qingdao Henger Ship Supplies Co., Ltd. is a new type of product that is used to install on the dock or ship to play a role in collision avoidance and buffering. According to the appearance, it is divided into three types: suspension type, sheath type, and thread type. After being filled with compressed air, it can float on the water (so it is also called floating fender or floating ball), which can be used as ship-to-ship berthing STS (ship to ship) and ship-to-ship berthing STD (ship to dock). To dock) is an important buffer medium that absorbs the impact energy of ship motion and has a small recoil force on the ship. Compared with general rubber fenders, it is more practical and economical.

2.The structure of the inflatable ball of Qingdao Henger Ship Products Co., Ltd.1. The inner layer of glue. The rubber layer on the inner wall of the fender is used to prevent gas leakage and maintain the air pressure of the fender. The rubber used in the Nanhai airbag is more elastic, cohesive, and gas-retaining.
2. Outer glue. The rubber layer covering the outside of the fender is used to protect the fender frame material and inner rubber from external force damage or abrasion. The anti-collision fender is not affected under any severe weather conditions.
3. Skeleton nylon 6" cord. As the frame material, nylon 6" cord belongs to the strong layer of the anti-collision fender. The high-strength nylon cord used to make tires is used, and there are 90 (±1.5) nylon cords per 10 cm length. The Nanhai airbag adopts a reasonable overall winding method, so that the force contraction rate of each part of the inflatable rubber fender is significantly greater than the national standard.
4. End flange. The metal parts placed on both sides of the fender can be used for hoisting and charging and exhausting.

3. Movement limiting device of fender system

1. Tyre network type: several rubber tires are tied to the ball, and the two ends are tied to a special lifting ring, which can be flexibly rotated. It is suitable for large leaning ball.
2. Rubber network type: Bundled with a special rubber pad on the sphere, it will be freely stretched and deformed when squeezed. Suitable for small and medium sized ball.
3. Rope network type: use nylon rope to woven into a net sleeve, tightly hoop on the sphere. It is suitable for small leaning ball.
4. Threaded fender: The threaded inflatable rubber fender is a brand new design, with high-strength rubber ribs outside the sphere.

4. Pneumatic rubber fender Parameter

5.Features and advantages of inflatable rubber fender

1. The inner layer of glue. The rubber layer on the inner wall of the fender is used to prevent gas leakage and maintain the air pressure of the fender. The rubber used in the Nanhai airbag is more elastic, cohesive, and gas-retaining.
2. Outer glue. The rubber layer covering the outside of the fender is used to protect the fender frame material and inner rubber from external force damage or abrasion. The anti-collision fender is not affected under any severe weather conditions.
3. Skeleton nylon 6" cord. As the frame material, nylon 6" cord is the strong layer of the anti-collision fender. The high-strength nylon cord used to make tires is used, and there are 90 (±1.5) nylon cords per 10 cm length. The Nanhai airbag adopts a reasonable overall winding method, so that the force contraction rate of each part of the inflatable rubber fender is significantly greater than the national standard.
4. End flange. The metal parts placed on both sides of the fender can be used for hoisting and charging and exhausting.

6. Pneumatic Rubber Fender Transportation

Transportation We can take the deflation pallet transportation and the entire

fender transportation without deflation according to the requirements of customers.

We always put the customer's requirements first.

7.Rubber fenders for storage inflatable boats:

1. When the Pneumatic rubber fender is not used for a long time, it should be washed and dried, filled with appropriate compressed air, placed in a dry, cool, ventilated place.Inventory temperature is maintained at -15 ℃ -40 ℃ .

2 .The place where the fender is stored should be kept away from the heat source.

3 .Fenders shall not be in contact with acids, alkalis, greases and organic solvents.

4 .When the fenders are not in use, they must not be stacked and should not be stacked on the ba. In order to better extend the service life of pneumatic rubber fenders, it is recommended that you store them in strict accordance with the above recommendations.

8. After-sale service

Quality is the cornerstone, service is the soul.

We continue to provide our customers with stable & reliable quality pneumatic rubber fenders with a comprehensive system of technical support, meticulous and thoughtful after-sales service to win customers trust and satisfaction.

Qingdao Henger Shipping Supplies Co., Ltd provides following services to all customers.

1. 24 hours instant online technical consultation and support.

2. 24 months warranty period(without any artificial damage) and free repairing service within warranty period.

3. lifetime reparing service.

9.Why choose us?

Our PAYMENT TERMS:

We can accept T/T 30% In Advance and 70% T/T Before Shipment.

We can accept a prepayment of 30% for the first cooperation. In the second cooperation, I can apply for a better payment term from the boss.

About the quality:

1. With ISO17357 DNV - GL inspection, CCS inspection (Rubber Material Testing, Product Size Testing, Air Tightness Testing, Pressure Testing)

2. The factory quality inspection report issued by Henger, and if the customer needs it, a video inspection certificate can be issued when the product quality inspection is performed before the product leaves the factory. On the premise that the buyer bears the cost, a third-party testing agency can be invited to conduct product testing.

About the production process:

1. After the fender is produced, it will stand still for 48 hours in strict accordance with the requirements to check the product quality.

2. Before leaving the factory, each product will be strictly tested for air tightness, and a dedicated technician will use soapy water to detect air leakage. Once there is a quality problem, it is absolutely not allowed to leave the factory and sell it.

• There will be specialized technicians to test the inflation pressure of each product to ensure that the product passes 100%.

4. The gas nozzle can be replaced by customers. The fender can be used for a long time, and the valve core may be aging. Customers can replace it by themselves.Prevent problems due to aging

About service:

1. In the future, I will be responsible for the business docking of your company, and I will serve the whole process by myself to reduce communication time.

2. I will add you in our company's VIP customer list, and we will deal with your business as the focus in the first time.

To sum up:

Based on the above three points, we believe that our products are fully in line with the market positioning at this price. Both the quality of the products and our services are among the top in the industry. We are committed to building a professional technical team and service team. Therefore, we will do our best in product quality processing and sales service attitude.
