Polyurethane Pneumatic Rubber Fender Floating Dock Eva Foam Fender High Wear Resistance

Key Attributes
Brand Name: Henger
Model Number: 012
Place of Origin: China
Certification: Iso 9001、BV、ccs
Minimum Order Quantity: 1pcs
Supply Ability: 50pcs week
Delivery Time: 5day
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Standard Packaging: Naked/Pallet

Product Summary

Polyurethane Floating Dock Eva Foam Fender EVA is a new polymer synthetic material between rubber and plastic. She has both high strength of plastic and high elasticity of rubber. Has its characteristics: 1. High wear resistance is 3-5 times that of natural rubber 2. The oil resistance is 4 times ...

Product Custom Attributes

Highlight

marine boat fenders

,

inflatable marine fenders

Product Name:
EVA Foam Fender/Foam Solid Filled Fender/Solid Fender
Material:
High Density Foam/Polyurea Coating
Specification:
DIA 0.5m-4.5m, L 0.7m-9m/Customized
Certificate:
CCS / BV / LR / ISO17357/DNV/SGS
Shelf Life:
24 Months
Service Life:
10-15 Years
Application:
Dock,Ship,Ship To Ship
Production Time:
5-10 Days
Accessories:
Tyre Sheath/Swivel/Shackle/Chain
Color:
Orange/Gray/Black/Customized
Product Description

Polyurethane Floating Dock Eva Foam Fender





EVA is a new polymer synthetic material between rubber and plastic. She has both high strength of plastic and high elasticity of rubber.


Has its characteristics:
1. High wear resistance is 3-5 times that of natural rubber


2. The oil resistance is 4 times better than nitrile rubber


3. High mechanical strength, its tear strength, tear strength and ability to bear load are many times higher than ordinary rubber


4. Excellent resistance to alkali, low temperature and solvent

5. High bonding strength with metal skeleton board

Polyurethane Pneumatic Rubber Fender Floating Dock Eva Foam Fender High Wear Resistance 0Polyurethane Pneumatic Rubber Fender Floating Dock Eva Foam Fender High Wear Resistance 1



Polyurethane Floating Dock Eva Foam Fender product advantages:


1. With floating performance, the installation position is not affected by tide difference


2. There is no need to check during use, no inflation, no fear of scratching, no friction, seawater resistance, acid and alkali resistance, the service life is up to 10-15 years, and it is maintenance free.


3. There is no danger of blasting and it is safe


4. It has better energy absorption performance and lower reaction force performance. When the compression is 60%, the reaction force is obvious from small to large, and the energy absorption is extremely high.


5. The product specifications are manufactured according to the needs, the largest specifications in the ship fender


6. Various colors can be applied to the fender surface, the product is smooth and beautiful, and the logo is obvious


7. Adopt chain hanging, easy to install, easy to move, free choice of chain tire net, increase the service life of fender





Technical Parameter

Model

D

(mm)

L

(mm)

compressibility 60%

Weight

(kg)

counter-force

(KN)

Energy Absorption

(KJ)

Ø 500×1000L 500 1000 71 8 34
Ø 600×1000L 600 1000 86 12 45
Ø 700×1500L 700 1500 161 27 101
Ø 1000×1500L 1000 1500 205 49 206
Ø 1000×2000L 1000 2000 274 64 275
Ø 1200×2000L 1200 2000 337 93 405
Ø 1200×2400L 1200 2400 390 110 475
Ø 1350×2500L 1350 2500 463 145 626
Ø 1500×3000L 1500 3000 624 216 927
Ø 1700×3000L 1700 3000 696 273 1191
Ø 2000×3500L 2000 3500 990 456 1923
Ø 2000×4000L 2000 4000 1110 505 2298
Ø 2200×4500L 2200 4500 1396 679 2992
Ø 2500×4000L 2500 4000 1386 781 3434
Ø 2500×5000L 2500 5000 1750 985 4272
Ø 3000×5000L 3000 5000 2050 1410 6411
Ø 3000×6000L 3000 6000 2460 1695 7293
Ø 3300×6500L 3300 6500 2950 2245 8335
Ø 4500×9000L 4500 9000 19650 7860

21460



Polyurethane Pneumatic Rubber Fender Floating Dock Eva Foam Fender High Wear Resistance 2

Polyurethane Pneumatic Rubber Fender Floating Dock Eva Foam Fender High Wear Resistance 3





If you have any interest or need, please feel free to contact me, I will always be there.

Thank you for reading.
