Product Details:
Payment & Shipping Terms:
|
| Product Nam: | Marine Rubber Airbag / Ship Launching Airbag / Salvage Airbag / Heavy Lifting Airbag | Size: | D15*L20m Ship Launching Airbag |
|---|---|---|---|
| Layer: | 5/ 6/ 7 / 8 / 9 / 10 Layers | Delivery Time: | 7-10days |
| Maximum Load: | 250T/ M | Certification: | CCS LRS GL SGS BV |
| Warranty Period: | 12 Months | Application: | Ship Launching Airbag / Salvage Airbag / Heavy Lifting Airbag |
| Packing: | Nude Packing / According To Shipping Requirements | Working Pressure: | 0.08Mpa |
| Highlight: | Lifting Marine Rubber Airbag,Ship Launching Marine Rubber Airbag,Marine Heavy Duty Airbags |
||
Airbags For Lifting Heavy Objects And Airbags For Ships Airbag Made Of Pure Natural Rubber
Heavy-duty lifting movement, airbag for ship launching and launching, is an innovative product with China's independent intellectual property rights, widely used in ship launching, caisson lifting and transportation, other heavy handling, floating aid for underwater installation, etc. field. The application of marine airbags is limited by the site and does not require large mechanical equipment, so it can shorten the engineering cycle and save a lot of money. After more than 20 years of development and practice, this product has proved to be safe, efficient, environmentally friendly, flexible and flexible.
Inflatable Marine Rubber Airbag Technical Parameter
| Model | D(m) | P(Mpa) | Working Height(m) | Unit Bearing Capacity(ton/m) | |||||
| 0.4D | 0.5D | 0.6D | 0.4D | 0.5D | 0.6D | ||||
| S1 |
S10 |
0.8 | 0.20 | 0.32 | 0.40 | 0.48 | 15.1 | 12.6 | 10.0 |
| 1 | 0.16 | 0.40 | 0.50 | 0.60 | 15.1 | 12.6 | 10.0 | ||
| 1.2 | 0.14 | 0.48 | 0.60 | 0.72 | 15.8 | 13.2 | 10.6 | ||
| 1.5 | 0.11 | 0.60 | 0.75 | 0.90 | 15.5 | 13.0 | 10.4 | ||
|
S11 |
0.8 | 0.19 | 0.32 | 0.40 | 0.48 | 14.3 | 11.9 | 9.5 | |
| 1 | 0.15 | 0.40 | 0.50 | 0.60 | 14.1 | 11.8 | 9.4 | ||
| 1.2 | 0.13 | 0.48 | 0.60 | 0.72 | 14.7 | 12.2 | 9.8 | ||
| 1.5 | 0.10 | 0.60 | 0.75 | 0.90 | 14.1 | 11.8 | 9.4 | ||
|
S12 |
0.8 | 0.24 | 0.32 | 0.40 | 0.48 | 18.1 | 15.1 | 12.1 | |
| 1 | 0.19 | 0.40 | 0.50 | 0.60 | 17.9 | 14.9 | 11.9 | ||
| 1.2 | 0.16 | 0.48 | 0.60 | 0.72 | 18.1 | 15.1 | 12.1 | ||
| 1.5 | 0.13 | 0.60 | 0.75 | 0.90 | 18.4 | 15.3 | 12.2 | ||
| 1.8 | 0.10 | 0.72 | 0.90 | 1.08 | 17.0 | 14.1 | 11.3 | ||
| S2 |
S20 |
1 | 0.24 | 0.40 | 0.50 | 0.60 | 22.6 | 18.8 | 15.1 |
| 1.2 | 0.20 | 0.48 | 0.60 | 0.72 | 22.6 | 18.8 | 15.1 | ||
| 1.5 | 0.16 | 0.60 | 0.75 | 0.90 | 22.6 | 18.8 | 15.1 | ||
| 1.8 | 0.13 | 0.72 | 0.90 | 1.08 | 22.0 | 18.4 | 14.7 | ||
| 2 | 0.12 | 0.80 | 1.00 | 1.20 | 22.6 | 18.8 | 15.1 | ||
|
S21 |
1 | 0.27 | 0.40 | 0.50 | 0.60 | 25.4 | 21.2 | 17.0 | |
| 1.2 | 0.23 | 0.48 | 0.60 | 0.72 | 26.0 | 21.7 | 17.3 | ||
| 1.5 | 0.18 | 0.60 | 0.75 | 0.90 | 25.4 | 21.2 | 17.0 | ||
| 1.8 | 0.15 | 0.72 | 0.90 | 1.08 | 25.4 | 21.2 | 17.0 | ||
| 2 | 0.14 | 0.80 | 1.00 | 1.20 | 26.4 | 22.0 | 17.6 | ||
|
S22 |
1 | 0.31 | 0.40 | 0.50 | 0.60 | 29.2 | 24.3 | 19.5 | |
| 1.2 | 0.26 | 0.48 | 0.60 | 0.72 | 29.4 | 24..5 | 19.6 | ||
| 1.5 | 0.20 | 0.60 | 0.75 | 0.90 | 28.3 | 23.6 | 18.8 | ||
| 1.8 | 0.17 | 0.72 | 0.90 | 1.08 | 28.8 | 24.0 | 19.2 | ||
| 2 | 0.15 | 0.80 | 1.00 | 1.20 | 28.3 | 23.6 | 18.8 | ||
| 2.5 | 0.12 | 1.00 | 1.25 | 1.50 | 28.3 | 23.6 | 18.8 | ||
| S3 |
S30 |
1 | 0.35 | 0.40 | 0.50 | 0.60 | 33.0 | 27.5 | 22.0 |
| 1.2 | 0.29 | 0.48 | 0.60 | 0.72 | 32.8 | 27.3 | 21.9 | ||
| 1.5 | 0.23 | 0.60 | 0.75 | 0.90 | 32.5 | 27.1 | 21.7 | ||
| 1.8 | 0.19 | 0.72 | 0.90 | 1.08 | 32.2 | 26.8 | 21.5 | ||
| 2 | 0.17 | 0.80 | 1.00 | 1.20 | 32.0 | 26.7 | 21.4 | ||
| 2.5 | 0.14 | 1.00 | 1.25 | 1.50 | 33.0 | 27.5 | 22.0 |
||
Introduction to Marine Airbag:
The production and application of marine airbags are mainly carried out with reference to two industry standards: CB/T3795 "Airbags for ship upper row and launch", CB/T3837 "Technical requirements for ship airbags upper row and launch".
The "Basic Requirements and Evaluation Methods for Production Conditions of Ship Manufacturing Enterprises" formulated by the National Defense Science and Industry Commission includes airbag launching as an approved launching method, and stipulates that Class II Class I companies are allowed to use airbag launching methods, and The facilities and equipment for airbag launching have also put forward corresponding requirements.
Airbags For Ships Application areas:
Ships launching--
Ships adopt airbag launching technology After more than 20 years of practice, launching ships have developed from flat-bottomed ships with a dead weight of tens of tons to large ships with tens of thousands of tons. Practice has proved that the ship airbag launching technology is safe and reliable. This technology has been recognized by the shipbuilding industry and port construction industry at home and abroad, and the airbag launching technology has been promoted in the United States, Europe and Southeast Asia.
Airbags For Lifting Heavy Objects:
Heavy goods handling--
Marine airbags are widely used in caisson jacking, transportation and launching in port construction, as well as component displacement and launching.
Floating and salvage--
Marine airbags can produce large buoyancy and have a strong load-bearing capacity, and are now widely used in the rescue of stranded ships and other areas of buoyancy and salvage
Airbag storage:
When the airbag is not used for a long time, it should be washed and dried, filled with talcum powder, and placed in a dry, cool and ventilated place indoors. The airbag should be stretched out flat, not stacked, and no heavy objects should be stacked on the airbag.
Keep the airbag away from heat sources.
The air bag must not come into contact with acids, alkalis, grease and organic solvents.
Thanks for reading, if you have any interest or questions, please feel free to contact me.
