Product Details:
Payment & Shipping Terms:
|
| Product Name: | High Quality Mooring Rope | Item: | Kuralon Rope,Polypropylene, Nylon |
|---|---|---|---|
| Material: | Nylon,PP,polyester,polypropylene | Color: | White,yellow,blue,red,Black |
| Packing: | Reel, Woven Bag, Bundle | Diameter: | 6 - 160mm,8mm,12mm,60mm, 4mm-56mm |
| Application: | Mooring, Marine Outfitting,fishing, Etc | Structure: | 6 Strand Crosslay,3 Strand,3/8 Strand |
| High Light: | braided mooring rope,marine dock lines |
||
High Quality 100% UHMWPE Marine Mooring&Towing Rope For Ship
Our Company
The company mainly produces polypropylene (polypropylene), nylon (polyamide), polyester (polyester), polyester-acrylic hybrid, nylon, ultra-high molecular weight polyethylene series cable, Product diameter: 4mm~120mm, optional .The structure has 3 strands, 4 strands, 6 strands, 8 strands, 12 strands, and a double-woven 24-strand, 32-strand, 36-strand rope of various structural types.
The company's products have the characteristics of high strength, low elongation, anti-wear and anti-corrosion, and the performance indicators are in line with relevant national standards and international standards. Nowadays, the products have been widely used in deep sea mooring, marine engineering, ocean transportation, national defense military, port towing, water conservancy engineering and special equipment.
Mooring Rope Introduction
Multiple strands of rope used to tie ships. Requires tensile, impact, abrasion resistance, flexibility and softness.
In the past, steel cables, linen or cotton ropes were commonly used; after the emergence of synthetic fibers, most of them were made of nylon, polypropylene, vinylon, polyester, etc. In addition to light weight, high strength, good impact resistance and abrasion resistance, synthetic fiber ropes have the advantages of corrosion resistance, mildew resistance, and insect resistance. For example, the strength and abrasion fastness of nylon ropes are several times higher than hemp and cotton ropes, and the specific gravity of polypropylene ropes is less than water, which can float on the water and is easy and safe to operate. Chemical fiber cable is divided into 3 strands, multi-strand twisted cable and 8-strand, multi-strand twisted cable according to the processing structure. The 3-strand cable is generally 4-50 mm in diameter, and the 8-strand cable is generally 35-120 mm in diameter. In addition to chemical fiber ropes, they are also widely used in transportation, industry, mining, sports and fishery. According to the needs of special applications, metal materials can also be incorporated into the cable core.
Mooring Rope Specification
| Polymer Polyethylene Rope | ||||||
| DIA | CIR | WT | B/S | |||
| MM | INCH | INCH | KGS/100M | LBS/100FT | TON | KN |
| 6 | 1/4 | 3/4 | 2.3 | 1.5 | 4.3 | 42 |
| 8 | 5/16 | 1 | 3.7 | 2.5 | 6.7 | 66 |
| 10 | 13/32 | 1-1/4 | 5.6 | 3.7 | 9.7 | 95 |
| 12 | 15/32 | 1-1/2 | 7.9 | 5.3 | 13.3 | 131 |
| 14 | 9/16 | 1-3/4 | 10.6 | 7.1 | 17.8 | 174 |
| 16 | 5/8 | 2 | 13.7 | 9.2 | 22.9 | 225 |
| 18 | 23/32 | 2-1/4 | 17.3 | 11.6 | 28.8 | 282 |
| 20 | 13/16 | 2-1/2 | 21.2 | 14.3 | 35.3 | 346 |
| 22 | 7/8 | 2-3/4 | 25.6 | 17.2 | 42.5 | 416 |
| 24 | 15/16 | 3 | 30.4 | 20.4 | 50.3 | 493 |
| 26 | 1-1/32 | 3-1/4 | 35.7 | 24.0 | 58.8 | 576 |
| 28 | 1-1/8 | 3-1/2 | 41.3 | 27.8 | 67.8 | 665 |
| 30 | 1-3/16 | 3-3/4 | 47.4 | 31.8 | 77.5 | 760 |
| 32 | 1-1/4 | 4 | 53.9 | 36.2 | 87.8 | 860 |
| 34 | 1-11/32 | 4-1/4 | 60.8 | 40.8 | 98.6 | 966 |
| 36 | 1-7/16 | 4-1/2 | 68.1 | 45.8 | 110 | 1078 |
| 38 | 1-1/2 | 4-3/4 | 75.9 | 51.0 | 122 | 1196 |
| 40 | 1-19/32 | 5 | 84.0 | 56.5 | 135 | 1318 |
| 42 | 1-21/32 | 5-1/4 | 92.6 | 62.2 | 148 | 1447 |
| 44 | 1-3/4 | 5-1/2 | 102 | 68.3 | 161 | 1581 |
| 46 | 1-13/16 | 5-5/8 | 111 | 74.6 | 176 | 1720 |
| 48 | 1-7/8 | 6 | 121 | 81.3 | 190 | 1864 |
| 50 | 2 | 6-1/4 | 131 | 88.0 | 205 | 2013 |
| 52 | 2-1/16 | 6-1/2 | 142 | 95.3 | 221 | 2167 |
| 56 | 2-1/4 | 7 | 164 | 111 | 254 | 2490 |
| 60 | 2-3/8 | 7-1/2 | 189 | 127 | 289 | 2831 |
| 64 | 2-1/2 | 8 | 215 | 144 | 326 | 3191 |
| 68 | 2-11/16 | 8-1/2 | 242 | 163 | 364 | 3567 |
| 72 | 2-7/8 | 9 | 271 | 182 | 404 | 3961 |
| 80 | 3-5/32 | 10 | 335 | 225 | 488 | 4787 |
| 88 | 3-7/16 | 11 | 405 | 272 | 578 | 5669 |
| 96 | 3-13/16 | 12 | 481 | 324 | 673 | 6599 |
| Other sizes available upon request | ||||||
| Material | Polyamide Multifilament | Polyamide | PP Multifilament | PP Monofilament | Polyester | Polypropylene and Polyester Mixed |
| Spec.Density | 1.14 not floating | 1.14 not floating | 0.91 floating | 0.91 floating | 1.38 not floating | 0.95 floating |
| Melting Point | 215°C | 215°C | 165°C | 165°C | 260°C | 165/260°C |
| Abrasion Resistance | Very Good | Very Good | Medium | Medium | Good | Good |
| U.V.resistance | Very Good | Very Good | Medium | Medium | Good | Good |
| Temperature resistance | 100°C max | 120°C max | 60°C max | 60°C max | 100°C max | 70°C max |
