Customized Polypropylene Marine Accessories Manufacturer Mooring Rope For Ship Mooring Rope Details Polypropylene ropes are of average abrasion resistance and resistant to the chemically active habitat. The ropes are made according to the requirements of the standard EN ISO 1346 : 2004 (E). Material ...
Customized Polypropylene Marine Accessories Manufacturer Mooring Rope For Ship
Mooring Rope Details
| Material | Polyamide Multifilament | Polyamide | PP Multifilament | PP Monofilament | Polyester | Polypropylene and Polyester Mixed |
| Spec.Density | 1.14 not floating | 1.14 not floating | 0.91 floating | 0.91 floating | 1.38 not floating | 0.95 floating |
| Melting Point | 215°C | 215°C | 165°C | 165°C | 260°C | 165/260°C |
| Abrasion Resistance | Very Good | Very Good | Medium | Medium | Good | Good |
| U.V.resistance | Very Good | Very Good | Medium | Medium | Good | Good |
| Temperature resistance | 100°C max | 120°C max | 60°C max | 60°C max | 100°C max | 70°C max |
| Size | Weight | Breaking Strength | |||
| Cir(inch) | Dia(mm) | 220mm(kg) | 600ft(lb) | ton | KN |
| 1/2 | 4 | 1.2 | 2.20 | 0.23 | 2.2 |
| 3/4 | 6 | 3.7 | 6.80 | 0.62 | 6.1 |
| 1 | 8 | 6.6 | 12.00 | 1.10 | 10.8 |
| 1-1/4 | 10 | 11 | 20.00 | 1.63 | 16 |
| 1-1/2 | 12 | 15 | 27.50 | 2.35 | 23 |
| 1-3/4 | 14 | 21 | 38.50 | 3.27 | 32 |
| 2 | 16 | 28 | 51.00 | 3.90 | 38 |
| 2-1/4 | 18 | 35 | 64.00 | 4.90 | 48 |
| 2-1/2 | 20 | 43 | 78.80 | 6.00 | 59 |
| 2-3/4 | 22 | 52 | 95.30 | 7.10 | 70 |
| 3 | 24 | 62 | 114.00 | 8.40 | 82 |
| 3-1/4 | 26 | 73 | 134.00 | 9.70 | 95 |
| 3-1/2 | 28 | 87 | 160.00 | 11.00 | 108 |
| 3-3/4 | 30 | 98 | 180.00 | 12.60 | 123 |
| 4 | 32 | 110 | 202.00 | 14.00. | 137 |
| 4-1/2 | 36 | 140 | 257.00 | 17.50 | 170 |
| 5 | 40 | 172 | 315.00 | 21.00 | 206 |
| 5-1/2 | 44 | 205 | 376.00 | 25.30 | 248 |
| 6 | 48 | 245 | 449.00 | 30.30 | 297 |
| 6-1/2 | 52 | 282 | 517.00 | 34.70 | 340 |
| 7 | 56 | 315 | 577.00 | 39.50 | 385 |
| 7-1/2 | 60 | 365 | 669.00 | 44.70 | 438 |
Mooring Rope Specific nature
Our Company
The company mainly produces polypropylene (polypropylene), nylon (polyamide), polyester (polyester), polyester-acrylic hybrid, nylon, ultra-high molecular weight polyethylene series cable, Product diameter: 4mm~120mm, optional .The structure has 3 strands, 4 strands, 6 strands, 8 strands, 12 strands, and a double-woven 24-strand, 32-strand, 36-strand rope of various structural types.
The company's products have the characteristics of high strength, low elongation, anti-wear and anti-corrosion, and the performance indicators are in line with relevant national standards and international standards. Nowadays, the products have been widely used in deep sea mooring, marine engineering, ocean transportation, national defense military, port towing, water conservancy engineering and special equipment.
