| MOQ: | 1 Meter |
| Standard Packaging: | According To Customer Ordered |
| Delivery Period: | 5-8 Days |
| Payment Method: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Capacity: | 1 - 2000 Meters Per Week |
High Strength Multi-colored Sailing Rope UHMWPE Mooring Ropes For Ship
Our Company
The company mainly produces polypropylene (polypropylene), nylon (polyamide), polyester (polyester), polyester-acrylic hybrid, nylon, ultra-high molecular weight polyethylene series cable, Product diameter: 4mm~120mm, optional .The structure has 3 strands, 4 strands, 6 strands, 8 strands, 12 strands, and a double-woven 24-strand, 32-strand, 36-strand rope of various structural types.
The company's products have the characteristics of high strength, low elongation, anti-wear and anti-corrosion, and the performance indicators are in line with relevant national standards and international standards. Nowadays, the products have been widely used in deep sea mooring, marine engineering, ocean transportation, national defense military, port towing, water conservancy engineering and special equipment.
Mooring Rope Details
| Size | Weight | Breaking Strength | |||
| Cir(inch) | Dia(mm) | 220mm(kg) | 600ft(lb) | ton | KN |
| 1/2 | 4 | 1.2 | 2.20 | 0.23 | 2.2 |
| 3/4 | 6 | 3.7 | 6.80 | 0.62 | 6.1 |
| 1 | 8 | 6.6 | 12.00 | 1.10 | 10.8 |
| 1-1/4 | 10 | 11 | 20.00 | 1.63 | 16 |
| 1-1/2 | 12 | 15 | 27.50 | 2.35 | 23 |
| 1-3/4 | 14 | 21 | 38.50 | 3.27 | 32 |
| 2 | 16 | 28 | 51.00 | 3.90 | 38 |
| 2-1/4 | 18 | 35 | 64.00 | 4.90 | 48 |
| 2-1/2 | 20 | 43 | 78.80 | 6.00 | 59 |
| 2-3/4 | 22 | 52 | 95.30 | 7.10 | 70 |
| 3 | 24 | 62 | 114.00 | 8.40 | 82 |
| 3-1/4 | 26 | 73 | 134.00 | 9.70 | 95 |
| 3-1/2 | 28 | 87 | 160.00 | 11.00 | 108 |
| 3-3/4 | 30 | 98 | 180.00 | 12.60 | 123 |
| 4 | 32 | 110 | 202.00 | 14.00. | 137 |
| 4-1/2 | 36 | 140 | 257.00 | 17.50 | 170 |
| 5 | 40 | 172 | 315.00 | 21.00 | 206 |
| 5-1/2 | 44 | 205 | 376.00 | 25.30 | 248 |
| 6 | 48 | 245 | 449.00 | 30.30 | 297 |
| 6-1/2 | 52 | 282 | 517.00 | 34.70 | 340 |
| 7 | 56 | 315 | 577.00 | 39.50 | 385 |
| 7-1/2 | 60 | 365 | 669.00 | 44.70 | 438 |
| Material | Polyamide Multifilament | Polyamide | PP Multifilament | PP Monofilament | Polyester | Polypropylene and Polyester Mixed |
| Spec.Density | 1.14 not floating | 1.14 not floating | 0.91 floating | 0.91 floating | 1.38 not floating | 0.95 floating |
| Melting Point | 215°C | 215°C | 165°C | 165°C | 260°C | 165/260°C |
| Abrasion Resistance | Very Good | Very Good | Medium | Medium | Good | Good |
| U.V.resistance | Very Good | Very Good | Medium | Medium | Good | Good |
| Temperature resistance | 100°C max | 120°C max | 60°C max | 60°C max | 100°C max | 70°C max |
Mooring Rope Specific nature
|
|
