Product Details:
Payment & Shipping Terms:
|
| Type: | Yokohama | Temperature Range: | -20-50°C |
|---|---|---|---|
| Material: | Rubber，SS | Corrosion Resistance: | Good |
| Color: | Black,grey | Application: | STS /STD/Ship To Ship/ship To Dock |
| Size: | Customized | Abrasion Resistance: | Good |
| High Light: | -20-50°C Customized Wharf Protection Fender,Customized Wharf Protection Fender |
||
The Pneumatic Rubber Fender is a type of marine fender designed to provide ultimate protection for ships during berthing and mooring operations. It is also known as the Inflatable Boat Fender, Yokohama Rubber Fender, or simply the Pneumatic Fender. Its innovative design and superior performance have made it a popular choice among ship owners and port operators worldwide.
The Pneumatic Rubber Fender is suitable for a wide range of applications, including STS (Ship to Ship) operations, STD (Ship to Dock) operations, and Ship to Ship operations. It is also commonly used for berthing and mooring of various types of vessels, including cargo ships, tankers, and cruise ships.
The Pneumatic Rubber Fender can withstand extreme temperatures, making it suitable for use in a wide range of weather conditions. Its temperature range is -20-50°C, making it suitable for use in both hot and cold climates.
The Pneumatic Rubber Fender comes in two different initial internal pressures: 50Kpa and 80Kpa. This allows for customization and ensures that the fender can meet the specific needs and requirements of different vessels and berthing conditions.
The Pneumatic Rubber Fender is available in two colors: black and grey. These colors not only give the fender a sleek and modern look, but they also make it easy to spot in the water, ensuring safety during berthing and mooring operations.
The Pneumatic Rubber Fender is made of high-quality rubber that is highly abrasion-resistant. This means that it can withstand the constant friction and impact of vessels during berthing and mooring operations, ensuring long-lasting performance and durability.
In summary, the Pneumatic Rubber Fender is a top-of-the-line marine fender that offers superior protection, durability, and versatility. Its application, temperature range, initial internal pressure, color options, and abrasion resistance make it the perfect choice for ship owners and port operators looking for a reliable and efficient solution for marine protection. Choose the Pneumatic Rubber Fender for your next berthing and mooring operation and experience the difference first-hand.
| Pneumatic 50 fender size and performance requirements | ||||
|
Nominal size diameter x length mm |
Initial internal pressure kPa |
Guaranteed energy absorption (GEA) | Reaction force at GEA deflection(R) | Hull pressure (Internal pressure) at GEA deflection (P) |
| Minimum value at deflection 60±5% kJ | Tolerance±10 % kN |
Reference value kPa |
||
| 500 x 1000 | 50 | 6 | 64 | 132 |
| 600 x 1000 | 50 | 8 | 74 | 126 |
| 700 x 1500 | 50 | 17 | 137 | 135 |
| 1000 x 1500 | 50 | 32 | 182 | 122 |
| 1000 x 2000 | 50 | 45 | 257 | 132 |
| 1200 x2000 | 50 | 63 | 297 | 126 |
| 1350 x 2500 | 50 | 102 | 427 | 130 |
| 1500 x 3000 | 50 | 153 | 579 | 132 |
| 1700 x 3000 | 50 | 191 | 639 | 128 |
| 2000 x 3500 | 50 | 308 | 875 | 128 |
| 2500 x 4000 | 50 | 663 | 1381 | 137 |
| 2500 x5500 | 50 | 943 | 2019 | 148 |
| 3300 x 4500 | 50 | 1175 | 1884 | 130 |
| 3300 x 6500 | 50 | 1814 | 3015 | 146 |
| 3300 x 10600 | 50 | 3067 | 5257 | 158 |
| 4500 x 9000 | 50 | 4752 | 5747 | 146 |
| 4500 x 12000 | 50 | 6473 | 7984 | 154 |
Our Pneumatic Rubber Fenders can be customized according to your specific requirements. We offer the following customization options:
By customizing your Pneumatic Rubber Fender, you can enjoy the following benefits:
To place an order for our customized Pneumatic Rubber Fenders or to learn more about our customization options, please contact us at:
Email: info@hengerfender.com
Phone: +86-123456789
We look forward to serving you and providing the best Pneumatic Rubber Fender for your ship or marine structure!
Our Pneumatic Rubber Fender is carefully packaged and shipped to ensure its safe arrival to our customers. We understand the importance of protecting our products during transportation, so we take great care in our packaging process.
Each Pneumatic Rubber Fender is individually wrapped in protective material and then placed in a sturdy cardboard box. This helps to prevent any damage during handling and transportation.
The cardboard boxes are then stacked on pallets and shrink-wrapped to further secure and protect the fenders. We also add additional padding and cushioning materials in between the boxes to prevent any movement or shifting during transportation.
We offer various shipping options to meet the specific needs of our customers. Our standard shipping method is by sea, which allows for cost-effective and reliable transportation for our fenders.
For urgent orders, we also offer air freight shipping services. This option is faster but may come at a higher cost.
We work closely with our trusted shipping partners to ensure timely delivery and proper handling of our products. We provide all necessary documents and certificates for international shipments.
Once the fenders are shipped, we will provide our customers with a tracking number so they can easily monitor the status of their shipment.
At Pneumatic Rubber Fender, we strive to provide the best packaging and shipping services to ensure our products arrive in top condition to our customers.
