High Safety Level Marine Rubber Fender Pneumatic Rubber Fenders For Floating And Shipping

China Qingdao Henger Marine Supply Co., Ltd certification
China Qingdao Henger Marine Supply Co., Ltd certification
we worked with Henger for 4 years, the fenders are high quality without any problems. their salesmen are all very kind and professional.

—— Paulo Anderson

Henger is the best supplier I've ever met in China for pneumatic floating fenders and foam fenders. their fenders are really real-stuff products without cutting workmanship and materials.

—— Tim

Henger has very strong R&D capability, which customized many high-tech products for our institution. wish to have better cooperation with Henger in wider marinetime area.

—— Dr. Kamran Khan

I'm Online Chat Now

High Safety Level Marine Rubber Fender Pneumatic Rubber Fenders For Floating And Shipping

High Safety Level Marine Rubber Fender Pneumatic Rubber Fenders For Floating And Shipping
High Safety Level Marine Rubber Fender Pneumatic Rubber Fenders For Floating And Shipping High Safety Level Marine Rubber Fender Pneumatic Rubber Fenders For Floating And Shipping High Safety Level Marine Rubber Fender Pneumatic Rubber Fenders For Floating And Shipping High Safety Level Marine Rubber Fender Pneumatic Rubber Fenders For Floating And Shipping

Large Image :  High Safety Level Marine Rubber Fender Pneumatic Rubber Fenders For Floating And Shipping

Product Details:

Place of Origin: Qingdao
Brand Name: HENGER
Certification: CCS.ABS.LRS.BV.GL.DNV.NK
Model Number: D2000mm*L3500mm

Payment & Shipping Terms:

Minimum Order Quantity: 1 Piece
Packaging Details: Nude Packing/Pallet/Box
Delivery Time: 10 Work Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 30 Pcs Per Week
Detailed Product Description
Color: Black/White/Others Material: Natural Rubber
Lifespan: 6-10 Years Initial Internal Pressure: 0.05MPa/0.08MPa
Part: Marine Fender Warranty: 24 Months
Usage: Protect Boat Quality: Durable
High Light:

navy boat fenders

,

large yacht fenders

High Safety Level Marine Rubber Fender Pneumatic Rubber Fenders For Floating And Shipping



Product Description:



Pneumatic Rubber Fender is constructed of synthetic-cord-reinforced rubber sheets with compressed air inside to keep floating over the water surface and work as a shock absorber between two ships or between ships and berthing structure when they come alongside each other on the water.

Pneumatic Rubber Fender is a leading anti-collision device for marine application in the world today. Pneumatic Fender has become an idea ship protection medium used extensively by large tankers, LPG vessels, ocean platforms, large docks, harbors and wharves.



High Safety Level Marine Rubber Fender Pneumatic Rubber Fenders For Floating And Shipping 0



Type I: pneumatic rubber fender with Chain & tyre net protective jacket

Type II: Sling type with rubber plate, rubber tube & ropes protective jacket

Type III: Ribbed type rubber fender

Type IV: Rope net type protective jacket rubber fender

Type V: Standard type without any protective jackets

Type VI: hydro pneumatic rubber fender

Pneumatic Rubber Fender Application:

1. Oil and gas tankers
2. Fast ferries and aluminum vessels
3. Temporary and permanent installations
4. Rapid response and emergencies
5. In ports with extreme tidal variations
6. For ship-to-ship lightering operations
7. For all navy vessels due to low hull pressure and the advantage of a proportional increase of reaction force and energy absorption



High Safety Level Marine Rubber Fender Pneumatic Rubber Fenders For Floating And Shipping 1



Product Specifications



Pneumatic 50 fender size and performance requirements

Nominal size diameter x length

mm

Initial internal pressure

kPa

Guaranteed energy absorption (GEA) Reaction force at GEA deflection(R) Hull pressure (Internal pressure) at GEA deflection (P)
Minimum value at deflection 60±5% kJ Tolerance±10 % kN

Reference value

kPa

500 x 1000 50 6 64 132
600 x 1000 50 8 74 126
700 x 1500 50 17 137 135
1000 x 1500 50 32 182 122
1000 x 2000 50 45 257 132
1200 x2000 50 63 297 126
1350 x 2500 50 102 427 130
1500 x 3000 50 153 579 132
1700 x 3000 50 191 639 128
2000 x 3500 50 308 875 128
2500 x 4000 50 663 1381 137
2500 x5500 50 943 2019 148
3300 x 4500 50 1175 1884 130
3300 x 6500 50 1814 3015 146
3300 x 10600 50 3067 5257 158
4500 x 9000 50 4752 5747 146
4500 x 12000 50 6473 7984 154



Pneumatic 80 fender size and performance requirements

Nominal size diameter x length

mm

Initial internal pressure

kPa

Guaranteed energy absorption (GEA) Reaction force at GEA deflection (R) Hull pressure (Internal pressure) at GEA deflection (P)
Minimum value at deflection 60±5% kJ Tolerance±10% kN

Reference value

kPa

500 x 1000 80 8 85 174
600 x 1000 80 11 98 166
700 x 1500 80 24 180 177
1000 x 1500 80 45 239 160
1000 x2000 80 63 338 174
1200 x 2000 80 88 390 166
1350 x 2500 80 142 561 170
1500 x 3000 80 214 761 174
1700 x 3000 80 267 840 168
2000 x 3500 80 430 1150 168
2500 x 4000 80 925 1815 180
2500 x 5500 80 1317 2653 195
3300 x 4500 80 1640 2476 171
3300 x 6500 80 2532 3961 191
3300 x 10600 80 4281 6907 208
4500 x 9000 80 6633 7551 192
4500 x 12000 80 9037 10490 202



Product Applications



Pneumatic Rubber Fender is constructed of synthetic-cord-reinforced rubber sheets with compressed air inside to keep floating over the water surface and work as a shock absorber between two ships or between ships and berthing structure when they come alongside each other on the water.

Pneumatic Rubber Fender is a leading anti-collision device for marine application in the world today. Pneumatic Fender has become an idea ship protection medium used extensively by large tankers, LPG vessels, ocean platforms, large docks, harbors and wharves.



Pneumatic Rubber Fenders are suitable for many applications including:

1. Tankers, Gas Carries and Bulk Cargo Ships;

2. Fast ferries and aluminum hulled vessels;

3. Temporary of permanent installations;

4. Rapid response and emergency fendering;

5. As stand-off fenders to realign ships with shore facilities.

High Safety Level Marine Rubber Fender Pneumatic Rubber Fenders For Floating And Shipping 2



Pneumatic Rubber Fender Inflation process:



1. Install the inflatable rod

2. Remove the valve core with the wrench

3. Link up quick connector inflation, inflation pressure 0.05-0.08mpa, recommended pressure 0.05mpa.

4. pressure by gauge

5. Screw the valve core with the wrench



High Safety Level Marine Rubber Fender Pneumatic Rubber Fenders For Floating And Shipping 3



Company Introduction:



Qingdao Henger Shipping Supplies Co., Ltd

Lies in Qingdao, a beautiful coastal city with red tiling and green trees, blue sea and clear sky, Qingdao Henger Shipping Supplies Co., Ltd is a high-tech enterprise integrated with manufacturing, research and innovation, technical services, specialized in manufacturing marine products, such as marine rubber fender, marine airbag, navigation mark and marine buoy. All products get ISO 9001-2008 certificate and IACS quality authentication from CCS, BV, GL, ABS, LG, etc. With strong technology base, advanced manufacturing technique, complete manufacturing facilities and well-equipped checkout equipment, Qingdao Henger Marine Supplies Co., Ltd is devoted to forge itself into a top-ranking international competitive marine products manufacturer providing high quality products and perfect service for all customers, and shoulder the responsibility of ensuring global marine safety via mutually beneficial cooperation with friends all over the world.
