Qingdao Henger Shipping Supply Co., Ltd
Home ProductsSteel Mooring Buoy

Modular Anchor Pendant Marine Steel Mooring Buoys Foam Filled Buoys

China Qingdao Henger Shipping Supply Co., Ltd certification
China Qingdao Henger Shipping Supply Co., Ltd certification
we worked with Henger for 4 years, the fenders are high quality without any problems. their salesmen are all very kind and professional.

—— Paulo Anderson

Henger is the best supplier I've ever met in China for pneumatic floating fenders and foam fenders. their fenders are really real-stuff products without cutting workmanship and materials.

—— Tim

Henger has very strong R&D capability, which customized many high-tech products for our institution. wish to have better cooperation with Henger in wider marinetime area.

—— Dr. Kamran Khan

I'm Online Chat Now

Modular Anchor Pendant Marine Steel Mooring Buoys Foam Filled Buoys

Modular Anchor Pendant Marine Steel Mooring Buoys Foam Filled Buoys
Modular Anchor Pendant Marine Steel Mooring Buoys Foam Filled Buoys Modular Anchor Pendant Marine Steel Mooring Buoys Foam Filled Buoys Modular Anchor Pendant Marine Steel Mooring Buoys Foam Filled Buoys Modular Anchor Pendant Marine Steel Mooring Buoys Foam Filled Buoys

Large Image :  Modular Anchor Pendant Marine Steel Mooring Buoys Foam Filled Buoys

Product Details:
Place of Origin: China
Brand Name: Henger
Certification: ISO 9001
Model Number: HESMB
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: nude packing or customized
Delivery Time: 15-30 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50 pcs/week
Detailed Product Description
Name: Steel Mooring Buoy Material: Steel
Application: Ship Mooring Buoy Color: Customized Color
Diameter: 2000mm Height: 1200mm
High Light:

surplus steel buoys

,

foam filled buoys

Modular Anchor Pendant Steel Mooring Buoy



Steel Mooring Buoy Induction



Mooring Buoy is a floating body in the water, made of well sealed steel material or EVA material, providing mooring to ship. It is consisted of floating body, anchor chain and anchorage. Floating body is fixed on the water by anchor chain and anchorage. There is mooring shack and metal shackle on top of floating body. The mooring work is carried under specialized ship warping hawsers. The mooring buoy is divided into single-floater mooring type and double-floater mooring type. With single-floater mooring buoy, the ship would float around the floating body because of wind force and ocean current force. So most of harbors adopt double-floater mooring buoy for ships, which means ship bow and ship stern separately attached with mooring buoy. In this way, ships could be fixed on the water.



Modular Anchor Pendant Marine Steel Mooring Buoys Foam Filled Buoys 0



Steel Mooring Buoy Product Feature

1. Floating body is stable with compact and reasonable structure. It has perfect performance to resist impact and stormy waves



2. High toughness, strong performance to resist crack caused by environmental stress, suitable for various kinds of marine environment.



3. Lower floating body weight with higher loading capacity and better abrasion performance, easy to delivery and install, lower installation cost.



4. Good corrosion resistance and strong weather fastness, longer service life



5. Low attached marine organism, safe and environmental, low maintenance cost



Modular Anchor Pendant Marine Steel Mooring Buoys Foam Filled Buoys 1



Specification of 2.2m Steel Floating Buoy


1.Diameter: 2.2mm


2.Length: 2370mm


3.Volume: about 13m³/set


4.Weight: 2200kg/set


5.Material: Q235 Steel


6.Filled with Resilient Closed-Cell Polyethylene Foam


7.Surface: Optional Color Painting


8.Long Service Life, Free Maintenance



Modular Anchor Pendant Marine Steel Mooring Buoys Foam Filled Buoys 2



Steel Mooring Buoy Design & Installation



Modular Anchor Pendant Marine Steel Mooring Buoys Foam Filled Buoys 3



Modular Anchor Pendant Marine Steel Mooring Buoys Foam Filled Buoys 4

Modular Anchor Pendant Marine Steel Mooring Buoys Foam Filled Buoys 5



Steel Mooring Buoy Technical Parameter

Model Net Buoyancy D×H (m) Suitable for Ship Tonnage (t)
HESMB 2.0 3 2.0×1.74 <2000
HESMB 2.6 6 2.6×2.27 <5000
HESMB 3.6 19 3.6×2.14 <10000
HESMB 5.0 28.5 5.0×3.4 <12000
HESMB 5.5 31.2 5.5×3.0 <100000
HESMB 6.0 34.2 6.0×3.2 <150000
HESMB 8.0 40.3 8.0×2.46 <250000

*buoy sizes and buoyancy can be customized according to customer design.
