Product Details:
Payment & Shipping Terms:
|
| Product Name: | Marine Rubber Airbag / Ship Launching Airbag / Salvage Airbag / Heavy Lifting Airbag | Brand: | HENGER |
|---|---|---|---|
| Material: | Natural Rubber | Size: | D0.5-4.5 |
| Lifespan: | 8~10 Years | Layer: | 5/ 6/ 7 / 8 / 9 / 10 Layers |
| Working Pressure: | 0.05MPa-0.17MPa |
Inflatable Marine Rubber Airbag Introduction
6000 years ago, our ancestor begin to use log-rolling method to lift and move weights, which is still widely used in daily production and actual life nowadays. Marine rubber airbag is designed with soft rubber to lift and carry weights, based on log-rolling method.
Marine rubber airbag is an innovative product of Chinese own proprietary intellectual property rights. It has wide application like ship launching & upgrading, caisson lifting & moving, heavy weights lifting, underwater-engineering buoyancy aid. The marine rubber airbag is not limited to space and heavy machinery, which could efficiently shorten the construction period and save lots of funds.
Why Choose US
(1) The highest quality
The Inflatable Heavy LIfting Rubber Airbags are produced in full accordance with ISO14409 and ISO17682 standards, with the highest quality natural rubber and reinforced nylon thread. High pressure, anti-aging, anti-wear and explosion-proof.
(2) High-quality after-sales service
24-hour online service. Our international service hotline is 86-18561375951. Any problem can be solved with the help of our professional technical team.
(3) The fastest delivery time
We are very responsible and strong production capacity to ensure the fastest delivery speed.
Marine rubber airbag product introduction
Inflatable Heavy LIfting Rubber Airbags also have other names: rubber airbags, ship airbags, ship launch airbags, ship rescue airbags, ship rescue airbags, inflatable airbags, ship lifting airbags, airbags, made of rubber and multilayer dipped tire fabric.
The three main uses of airbags are: launching ships, lifting heavy objects, and rescuing.
Marine rubber airbags are now very popular among shipyards, shipowners and marine supplies companies.
Technical Requirement
Size:
Deviation between diameter and effective length: ±2%
Total length: ±4%
Elastic deformation: Under 1.2 times of working pressure, the diameter deformation is less than 5%.
Safety factor:> 4.5
Air tightness: pressure drop <5% after inflating for 1 hour
Surface quality: streamlined, no cracks, no bubbles, no double skin, no impurities, no obvious dirt and other obvious defects.
Explosion-proof design at the end.
Airbag for ship launching Specification
| Diameter(m) | 1.0 | 1.2 | 1.5 | 1.8 | 2.0 | |
| Medium Pressure (4-5) |
Test Pressure | 0.14-0.16 | 0.12-0.14 | 0.10-0.12 | 0.08-0.10 | 0.07-0.09 |
| Working Pressure | 0.12-0.14 | 0.10-0.12 | 0.08-0.10 | 0.07-0.09 | 0.06-0.08 | |
| High Pressure (6-8) |
Test Pressure | 0.22-0.26 | 0.20-0.24 | 0.15-0.20 | 0.13-0.16 | 0.12-0.15 |
| Working Pressure | 0.20-0.24 | 0.17-0.22 | 0.13-0.18 | 0.11-0.14 | 0.10-0.13 | |
Storage of the ship launching airbag
1. If the Inflatable Heavy LIfting Rubber Airbag is not used for a long time, the airbag should be kept dry. Spread talc powder on the surface of the airbag. Keep it in a dry and ventilated room away from the light source. Please keep the transport airbag in a safe place to avoid stretching, compression and deformation.
2. Keep away from heat sources.
3. Do not touch airbags that release acids, alkalis, grease and organic solvents.
4. It should be kept flat, not stacked, and without heavy objects.
FAQ
Question 1: What material do you use to produce airbags?
Answer: Our raw materials are natural rubber and nylon thread fabric impregnated with rubber
Question 2: Are you a trading company?
Answer: We are a company and factory located in Jimo, Qingdao, close to Qingdao Port and Qingdao Airport, with convenient transportation.
Question 3: Can you do OEM?
Answer: Yes, we can do it. As long as we receive your request, we can produce as required.
Question 4: What is the delivery time and payment terms you accept?
Answer: The delivery time depends on the size of the customer and the number of orders. You can choose the payment method, wire transfer at sight, letter of credit, Western Union and so on.
Question 5: Can you send me some samples?
Answer: We are honored to provide you with samples for quality inspection. Customers only need to confirm the shipping volume, and then they can send samples through FedEx, DHL, UPS, TNT, etc.
Question 6: What certificates can your company provide?
Answer: We can provide CCS, ABS, DNV, LR, BV certificates.
Question 7: How long is your warranty period?
Answer: Our warranty period is 24 months.
