Cylindrical Inflatable Rubber Marine Salvage Airbags

Cylindrical Inflatable Rubber Marine Salvage Airbags
Cylindrical Inflatable Rubber Marine Salvage Airbags
video play

Large Image :  Cylindrical Inflatable Rubber Marine Salvage Airbags

Product Details:
Place of Origin: China
Brand Name: Henger
Certification: Iso 9001、BV、ccs
Model Number: 016
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Packaging Details: paller
Delivery Time: 5day
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 50pcs week
Detailed Product Description
Product Nam: Marine Rubber Airbag / Ship Launching Airbag / Salvage Airbag / Heavy Lifting Airbag Size: D15*L20m Ship Launching Airbag
Layer: 5/ 6/ 7 / 8 / 9 / 10 Layers Delivery Time: 7-10days
Maximum Load: 250T/ M Certification: CCS LRS GL SGS BV
Warranty Period: 12 Months Application: Ship Launching Airbag / Salvage Airbag / Heavy Lifting Airbag
Packing: Nude Packing / According To Shipping Requirements Working Pressure: 0.08Mpa
High Light:

Inflatable Rubber Marine Salvage Airbags

,

Cylindrical Marine Salvage Airbags

,

Marine Ship Launching Airbag

Inflatable Heavy LIfting Rubber Airbags And Marine Launching Rubber Airbags



Airbag advantages:
Put a lot of uninflated cylindrical bladders under the bottom of the boat, then inflate the top of the boat, remove other obstacles below, and then slowly release the airbags at the back a little bit, and place the hull a little backward. If you use the power to push it a little bit in the front, the boat will naturally go into the water behind, and the boat will be launched.


Ship launching in the shipbuilding industry is a relatively complex process. Inland and coastal shipping ships generally use track sliding and airbag rolling methods. Track sliding requires a berth or dock. Due to high investment costs and small scope of application, it is generally only used. Selected by large shipyards. Marine airbags are widely used by small and medium-sized shipyards due to their small overall investment and wide range of applications.



Cylindrical Inflatable Rubber Marine Salvage Airbags 0



Inflatable Marine Rubber Airbag Technical Parameter



Model D(m) P(Mpa) Working Height(m) Unit Bearing Capacity(ton/m)
0.4D 0.5D 0.6D 0.4D 0.5D 0.6D
S1



S10

0.8 0.20 0.32 0.40 0.48 15.1 12.6 10.0
1 0.16 0.40 0.50 0.60 15.1 12.6 10.0
1.2 0.14 0.48 0.60 0.72 15.8 13.2 10.6
1.5 0.11 0.60 0.75 0.90 15.5 13.0 10.4



S11

0.8 0.19 0.32 0.40 0.48 14.3 11.9 9.5
1 0.15 0.40 0.50 0.60 14.1 11.8 9.4
1.2 0.13 0.48 0.60 0.72 14.7 12.2 9.8
1.5 0.10 0.60 0.75 0.90 14.1 11.8 9.4





S12

0.8 0.24 0.32 0.40 0.48 18.1 15.1 12.1
1 0.19 0.40 0.50 0.60 17.9 14.9 11.9
1.2 0.16 0.48 0.60 0.72 18.1 15.1 12.1
1.5 0.13 0.60 0.75 0.90 18.4 15.3 12.2
1.8 0.10 0.72 0.90 1.08 17.0 14.1 11.3
S2





S20

1 0.24 0.40 0.50 0.60 22.6 18.8 15.1
1.2 0.20 0.48 0.60 0.72 22.6 18.8 15.1
1.5 0.16 0.60 0.75 0.90 22.6 18.8 15.1
1.8 0.13 0.72 0.90 1.08 22.0 18.4 14.7
2 0.12 0.80 1.00 1.20 22.6 18.8 15.1





S21

1 0.27 0.40 0.50 0.60 25.4 21.2 17.0
1.2 0.23 0.48 0.60 0.72 26.0 21.7 17.3
1.5 0.18 0.60 0.75 0.90 25.4 21.2 17.0
1.8 0.15 0.72 0.90 1.08 25.4 21.2 17.0
2 0.14 0.80 1.00 1.20 26.4 22.0 17.6





S22

1 0.31 0.40 0.50 0.60 29.2 24.3 19.5
1.2 0.26 0.48 0.60 0.72 29.4 24..5 19.6
1.5 0.20 0.60 0.75 0.90 28.3 23.6 18.8
1.8 0.17 0.72 0.90 1.08 28.8 24.0 19.2
2 0.15 0.80 1.00 1.20 28.3 23.6 18.8
2.5 0.12 1.00 1.25 1.50 28.3 23.6 18.8
S3





S30

1 0.35 0.40 0.50 0.60 33.0 27.5 22.0
1.2 0.29 0.48 0.60 0.72 32.8 27.3 21.9
1.5 0.23 0.60 0.75 0.90 32.5 27.1 21.7
1.8 0.19 0.72 0.90 1.08 32.2 26.8 21.5
2 0.17 0.80 1.00 1.20 32.0 26.7 21.4
2.5 0.14 1.00 1.25 1.50 33.0 27.5 22.0






Airbag packaging and transportation:


According to the provisions of the CB/T 3795-1996 of the People's Republic of China Ship Industry Standard, the packaging, transportation and storage of marine airbags should comply with the following standards:


1. Packaging
Folded and packed with plastic woven bags.


2. Transportation
Airbags should be lifted, lifted, and rolled in an inflated state when transported on short distances. It is strictly forbidden to drag on the ground.


The airbag should be folded and fixed to the tray during long-distance transportation, with a cushion underneath, and wrapped with a wrapping film on the outside.



Cylindrical Inflatable Rubber Marine Salvage Airbags 1



Airbag storage:
1. When the airbag is not used for a long time, it should be washed and dried, filled with talcum powder on the outside, and placed in a dry, cool and ventilated place indoors.
2. The airbag should be stretched out and placed flat, not stacked, and no heavy objects should be stacked on the airbag.
3. The place where the air bag is stored should be far away from heat sources.
4. The air bag cannot be in contact with acid, alkali, grease and organic solvents.



Cylindrical Inflatable Rubber Marine Salvage Airbags 2



The damage forms of marine airbags can generally be divided into longitudinal cracks (cracks extending along the length of the airbag), transverse cracks (cracks extending in the circumferential direction), and nail holes (including disc-shaped damage within 10cm in diameter). The operation steps are as follows: 1) Delineate the repair range as the boundary of the polished surface. The repair scope should extend to the surrounding cracks, and do not miss any hidden injuries. The expansion range varies depending on the airbag model and damage range. Usually, the 3-layer is 18-20cm; the 4-layer is 20-22cm; the 5-layer is 22-24cm; and the 6-layer is 24-26cm.



Cylindrical Inflatable Rubber Marine Salvage Airbags 3



Service and transportation:


The product warranty period of Henger is 18 months, and the average supplier can not reach such a long time, which is also the trust we and customers have in our factory products.


After-sales service we are online 24 hours a day, as long as you have questions we will always be there, there will be professional staff to answer your questions and provide you with technical support.


Transportation We can take the deflation pallet transportation and the entire fender transportation without deflation according to the requirements of customers. We always put the customer's requirements first.
